Summary of Contents for Treasure Garden AG19A
- Page 1 Assembly and Operation Guide AG19A CANTILEVER AG19A 10’ octagon...
- Page 2 Thank you for purchasing Treasure Garden’s AG19A Cantilever. Please remove all contents from the package, inspect and review checklist. Some parts may be included in the styrofoam packaging. Do not discard any packaging or box until assembly is complete. CHECKLIST...
- Page 3 (4) washers from cross bar extenders to desired length (Fig. 2). Reattach (4) bolts and (4) washers and tighten using a 6mm hexagon wrench. Secure stand with (4) square stones, concrete weights or Treasure Garden base weights (all weights sold separately) (Fig 3). (Fig. 1) (Fig.
-
Page 4: Assemble Frame
STEP ASSEMBLE FRAME Carefully lift and insert bottom pole into base stem (Fig. 4) and tighten base stem clamp to secure in place (Fig. 5). (Fig. 4) (Fig. 5) - Page 5 STEP OPENING UMBRELLA IMPORTANT: PRIOR TO OPENING. To avoid personal injury or damage to the umbrella, make sure there is approximately 59” clearance behind umbrella from any furniture or structure. With one hand on the pole and the other on the cantilever arm (Fig. 6), slowly lift cantilever arm up until release column locks into place upward (Fig.
- Page 6 STEP TILTING UMBRELLA IMPORTANT: PRIOR TO USING TILT FEATURE. To avoid personal injury or damage to the umbrella, make sure the area around umbrella canopy is clear and free from any furniture or structure. Insert crank handle into “RIGHT/LEFT” socket, located on operation housing (Fig. 11). Turn crank handle to the left or right, to the angle you wish canopy to tilt (Fig.
- Page 7 STEP ROTATING UMBRELLA IMPORTANT: PRIOR TO ROTATING UMBRELLA. To avoid personal injury or damage to the umbrella, make sure the area around umbrella is clear and free from any furniture or structure. Loosen the base stem clamp by turning the clamp counter-clockwise. Rotate the umbrella to the desired position.
- Page 8 STEP CLOSING UMBRELLA IMPORTANT: When closing the umbrella, the canopy must be in a horizontal position, or damage to umbrella may occur. Insert crank handle into the “OPEN/CLOSED” socket, located on the operation housing (Fig. 16). Turn crank handle counter-clockwise until the umbrella canopy is closed (Fig. 17). Insert crank handle into the “ARM”...
-
Page 9: Care And Maintenance
CARE AND MAINTENANCE • When not in use, close and cover umbrella with a protective cover (not included). • Allow a wet canopy to dry while in open position, but do not leave unattended. • If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge. •... -
Page 10: Safety Precautions
SAFETY PRECAUTIONS • To reduce risk of personal injury in which a person is injured or harmed, and/or damage to personal property, read and follow the Assembly Guide prior to assembling and operating umbrella and base. • Close and store the umbrella in windy conditions or when a storm approaches. Never allow the umbrella to flap in the wind;... - Page 11 Simply contact your original authorized RUST: Rust is a natural part of the aging Treasure Garden dealer with a description process of steel or iron based materials, of the defect. The dealer will verify the and is therefore NOT considered a defect.
- Page 12 ©2022 Treasure Garden, Inc. - All Rights Reserved. v.11.07.22...
