４－４．Setting DRIVE CURRENT SELECT switch
(1) Set the switch No. to the setting specified in the table "10-4. Applicable Motors."
●Relationship between the DRIVE I.SEL switch No. and DRIVE CURRENT.
DRIVE I.SEL
No.
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
DRIVE CURRENT is set up with the DRIVE I.SEL switch.
A/phase
０ 0.30
１ 0.325
２ 0.35
３ 0.375
４ 0.40
５ 0.425
６ 0.45
７ 0.475
８ 0.50
９ 0.525
Ａ 0.55
Ｂ 0.575
Ｃ 0.60
Ｄ 0.65
Ｅ 0.70
Ｆ 0.75 (Factory setting）
CAUTION
