５－２．Mounting Method
(1) Fix the product at the two round holes on the main frame.
●Mounting example
Fixing with
a screw
Fixing with
a screw
The round holes on the main frame are used.
The following items are required:
● M-3 screw (8mm or more in length):
● M-3 spring washer:
● M-3 flat washer:
0 0
8
-24-
GDB-5K30
Instructions Manual
2
2
2
Fixing with a screw
M-3 screw
M-3 spring washer
M-3 flat washer
Fixing with a screw
M-3 screw
M-3 spring washer
M-3 flat washer
