４－４．Setting DRIVE CURRENT SELECT switch
(1) Set the switch No. to the setting specified in the table "10-4. Applicable Motors."
●Relationship between the DRIVE I.SEL switch No. and DRIVE CURRENT.
DRIVE I.SEL
No.
A high setting value may cause burn on the
skin due to overheating of the motor.
Do not select a high value beyond the
required.
DRIVE CURRENT is set up with the DRIVE I.SEL switch.
A/phase
０ 0.30
１ 0.325
２ 0.35
３ 0.50
４ 0.55
５ 0.60
６ 0.65
７ 0.70
８ 0.75
９ 0.80
Ａ 0.90
Ｂ 1.00
Ｃ 1.10
Ｄ 1.20
Ｅ 1.30
Ｆ 1.40 (Factory setting）
CAUTION
-18-
