Melec GDB-5K30 Instruction Manual page 8

●When setting up the PULSE INPUT TYPE SELECT switch:
●When setting up the ROTATE MODE SELECT switch:
●When setting up the EXTEND FUNCTION SELECT switch:
●When installing:
●When connecting the DC Input/ Motor Output Connectors (J2, J3):
CAUTION
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of the motor.
Ensure correct setting.
CAUTION
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of the motor.
Ensure correct setting.
CAUTION
Erroneous setting may cause breakage of
the machine or injury due to unexpected
rotation of the motor.
Ensure correct setting.
WARNING
Overheating may cause fire.
Mount it on a noncombustible member.
Keep it away from combustibles.
CAUTION
Erroneous connection may cause
breakage of the motor or the driver.
Correctly connect the DC Input/Motor
output connector.
-8-
GDB-5K30
Instructions Manual
