3.Name and Function of Each Section
3-1.Signal I/O Connector(J1)
DRIVER
J1
1
CW+
2
CW-
3
CCW+
4
CCW-
5
M.F+
6
M.F-
7
P.O+
8
P.O-
9
O.H.A+
10
O.H.A-
11
C.S+
12
C.S-
CW drive pulse signal input terminal
●Directs the motor to operate CW.
CCW drive pulse signal input terminal
●Directs the motor to operate CCW.
Motor excitation stop signal input terminal
●Shuts off output current to drive the motor.
Phase siganal output terminal
●Outputs the signal when the motor-excitation
state is the excitation home position.
Overheat alarm signal output terminal
●Outputs the signal when internal temperature
of the driver has reached approx. 70℃ or more.
Step angle switching signal input terminal
●Switches the step angle by 20 division.
