Melec GDB-5K30 Instruction Manual page 45

Fig.1
GDB-5K30
SH5281-7241(7211)
0.75A/PHASE
TORQUE(N･m)
0.10
HOLD 40% = 0.022 N・m
0.08
0.06
PULLOUT TORQUE
0.04
0.02
DRIVER INPUT CURRENT
0.00
0.01 0.1
MOTOR ROTATION SPEED(s
0.6 6
MOTOR ROTATION SPEED(r/min)
DRIVE I.SEL = NoF
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = ON, OFF, OFF, OFF
DRIVER INPUT CURRENT(A)
5.0
4.0
3.0
2.0
1.0
0.0
fs
1 10 100
-1 )
60 600 6000
Fig.2
GDB-5K30
SH5285-7241(7211)
0.75A/PHASE
TORQUE(N･m)
0.20
HOLD 40% = 0.040 N・m
0.16
0.12
PULLOUT TORQUE
0.08
0.04
DRIVER INPUT CURRENT
0.00
0.01 0.1
MOTOR ROTATION SPEED(s
0.6 6
MOTOR ROTATION SPEED(r/min)
-45-
GDB-5K30
Instructions Manual
DRIVE I.SEL = NoF
MOTOR SEL = OFF
RM1,RM2,RM3,RM4 = ON, OFF, OFF, OFF
DRIVER INPUT CURRENT(A)
5.0
4.0
3.0
2.0
1.0
0.0
fs
1 10 100
-1 )
60 600 6000
