１０－５．Torque Characteristics
(1) Representations in the torque characteristics table are made in terms of the
motor rotation (s
Motor rotation (s
Motor rotation(s
Motor rotation (s
Motor rotation(s
● Use the Motor rotation at 100s
(2) The Maximum Starting Pulse Rate is represented as "fs" by the value at zero
inertial load.
(3) Upon operation, provide adequate allowance for torque.
(4) The stepping motor may attain high temperature, depending on the operational
conditions.
Use the stepping motor according to the Instructions Manual produced by
motormakers.
-１
) vs. torque (N・m).
-１
) and drive pulse frequency (Hz) are converted as follows:
360°
-１
) ×
Step angle
-１
) and motor rotation (r/min) are converted as follows:
-１
) × 60
-1
(6000r/min) or less.
-44-
＝ Drive pulse input frequency(Hz)
＝ Motor rotation(r/min)
GDB-5K30
Instructions Manual
