AFL3-W15C/W19C-ULT3 Panel PC
MODEL:
AFL3-W15C/W19C-ULT3
Flat Bezel Panel PC with Intel® Core™ i5-6300U / Celeron® 3955U
CPU, Touchscreen, Four USB 3.0, Dual GbE LAN, RS-232/422/485,
HD Audio, Wi-Fi 802.11a/b/g/n/ac and RoHS
Rev. 1.00 - November 1, 2016
User Manual
User Manual
Page I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFL3-W15C-ULT3 and is the answer not in the manual?

Questions and answers

Summary of Contents for IEI Technology AFL3-W15C-ULT3

  • Page 1 AFL3-W15C/W19C-ULT3 Panel PC MODEL: AFL3-W15C/W19C-ULT3 Flat Bezel Panel PC with Intel® Core™ i5-6300U / Celeron® 3955U CPU, Touchscreen, Four USB 3.0, Dual GbE LAN, RS-232/422/485, HD Audio, Wi-Fi 802.11a/b/g/n/ac and RoHS User Manual User Manual Page I Rev. 1.00 - November 1, 2016...
  • Page 2 AFL3-W15C/W19C-ULT3 Panel PC Revision Date Version Changes November 1, 2016 1.00 Initial release Page II...
  • Page 3: Safety Instructions

    AFL3-W15C/W19C-ULT3 Panel PC Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 AFL3-W15C/W19C-ULT3 Panel PC Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
  • Page 5 AFL3-W15C/W19C-ULT3 Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 6: Manual Conventions

    AFL3-W15C/W19C-ULT3 Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.
  • Page 7: Mounting The System

    AFL3-W15C/W19C-ULT3 Panel PC 3.12 Mounting the System The methods of mounting the AFL3-W15C/W19C-ULT3 are listed below.  Wall mounting  Panel mounting  Rack mounting  Arm mounting  Stand mounting The mounting methods are described below. 3.12.1 Wall Mounting To mount the flat bezel panel PC onto the wall, please follow the steps below.
  • Page 8 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-21: Wall-mounting Bracket Step 6: Insert the four monitor mounting screws provided in the wall mount kit into the four screw holes on the real panel of the flat bezel panel PC and tighten until the screw shank is secured against the rear panel (Figure 3-22).
  • Page 9 AFL3-W15C/W19C-ULT3 Panel PC Step 7: Align the mounting screws on the monitor rear panel with the mounting holes on the bracket. Step 8: Carefully insert the screws through the holes and gently pull the monitor downwards until the monitor rests securely in the slotted holes (Figure 3-22). Ensure that all four of the mounting screws fit snugly into their respective slotted holes.
  • Page 10: Panel Mounting

    Step 1: Select the position on the panel to mount the panel PC. Cut out a section corresponding to the size shown below. The size must be Step 2: smaller then the outer edge. Figure 3-24: AFL3-W15C-ULT3 Cutout Dimensions Page 36...
  • Page 11 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-25: AFL3-W19C-ULT3 Cutout Dimensions Step 3: Slide the panel PC through the hole until the frame is flush against the panel. Insert a M5*50 screw into the screw hole on the side of the panel mounting Step 4: bracket.
  • Page 12 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-26: Panel Mounting Kit Installation Step 6: Align the panel mounting bracket screw holes with the VESA mounting holes on the rear of the panel PC. Secure the two panel mounting brackets to the rear of the panel PC by inserting Step 7: the four retention screws into the VESA mounting holes and tightening them (Figure...
  • Page 13 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-27: Securing Panel Mounting Brackets NOTE: The panel mounting kit described in this section is an optional item. To purchase it, please contact an IEI sales representative. Page 39...
  • Page 14: Cabinet And Rack Installation

    AFL3-W15C/W19C-ULT3 Panel PC 3.12.3 Cabinet and Rack Installation The AFL3-W15C/W19C-ULT3 flat bezel panel PC can be installed into a cabinet or rack. The installation procedures are similar to the panel mounting installation. To do this, please follow the steps below: NOTE: When purchasing the cabinet/rack installation bracket, make sure it is compatible with both the AFL3-W15C/W19C-ULT3 flat bezel panel PC...
  • Page 15 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-28: Rack Mounting Kit Installation Step 4: Align the rack mounting bracket screw holes with the VESA mounting holes on the rear of the panel PC. Secure the two rack mounting brackets to the rear of the panel PC by inserting Step 5: the four retention screws into the VESA mounting holes and tightening them (Figure 3-29).
  • Page 16 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-29: Securing Rack Mounting Brackets Step 6: Slide the panel PC with the attached rack/cabinet bracket into a rack or cabinet (Figure 3-30). Figure 3-30: Install into a Rack/Cabinet Page 42...
  • Page 17: Arm Mounting

    AFL3-W15C/W19C-ULT3 Panel PC Step 7: Once the panel PC with the attached rack/cabinet bracket has been properly inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to the front of the rack or cabinet (Figure 3-30). NOTE: The rack mounting kit described in this section is an optional item.
  • Page 18 AFL3-W15C/W19C-ULT3 Panel PC Figure 3-31: Arm Mounting Retention Screw Holes Step 4: Secure the AFL3-W15C/W19C-ULT3 to the interface pad by inserting four retention screws through the mounting arm interface pad and into the AFL3-W15C/W19C-ULT3.S t e p 0 : Figure 3-32: Arm Mounting Page 44...
  • Page 19: Stand Mounting

    AFL3-W15C/W19C-ULT3 Panel PC 3.12.5 Stand Mounting To mount the AFL3-W15C/W19C-ULT3 using the stand mounting kit, please follow the steps below. Step 1: Locate the screw holes on the rear of the AFL3-W15C/W19C-ULT3. This is where the bracket will be attached. Step 2: Align the bracket with the screw holes.
