AFL3-W15A-BT
Flat Bezel Panel PC
全平面平板電腦
Quick Installation Guide/快速安裝指南
Version 1.00
Packing List / 內容清單
1 x AFL3-W15A-BT panel PC / AFL3-W15A-BT 平板電腦
1 x Power adapter / 電源供應器 (60 W)
1 x Power cord / 電源線
1 x RJ-45 to DB-9 COM port cable / RJ-45 轉 DB-9 序列埠連接線
4 x Screws for VESA mounting / VESA 固定安裝螺絲
4 x Screws for HDD installation / 硬碟固定螺絲
2 x Screws for PCIe Mini card installation / PCIe Mini 卡固定螺絲
1 x Utility CD / 光碟
1 x One Key Recovery CD
1 x QIG (Quick Installation Guide) / 快速安裝指南

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFL3-W15A-BT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology AFL3-W15A-BT

Summary of Contents for IEI Technology AFL3-W15A-BT

  • Page 1 Quick Installation Guide/快速安裝指南 Version 1.00 Packing List / 內容清單 1 x AFL3-W15A-BT panel PC / AFL3-W15A-BT 平板電腦 1 x Power adapter / 電源供應器 (60 W) 1 x Power cord / 電源線 1 x RJ-45 to DB-9 COM port cable / RJ-45 轉 DB-9 序列埠連接線...

  • Page 2: Front Panel

    Front Panel The front side of the AFL3-W15A-BT is a flat-bezel panel with a 15.6” TFT LCD screen surrounded by a PC/ABS plastic frame. There is a power LED indicator located on the front panel. The status descriptions of the power LED indicator are listed below.

  • Page 3: Bottom Panel

    Bottom Panel The bottom panel of the AFL3-W15A-BT has the following connectors and switches. Back Cover Removal & Re-installation Remove - Remove the back cover retention screws. Slide the back cover until it is disengaged from the locking mechanism. Then, lift the back cover off the chassis.
  • Page 4 前面板 AFL3-W15A-BT 前面板是一個全平面的 15.6”TFT LCD 面板，四周圍繞著 PC/ABS 材質塑膠框。 前面板上有一個電源指示燈，此指示燈的狀態描述如下： 關閉: 未連接電源線或電源供應器失效  琥珀色: 系統已連接電源，隨時可開機  綠色: 系統為開機狀態  後面板 AFL3-W15A-BT 後面板上有支援 VESA 固定設備的螺絲孔...
  • Page 5 底部面板 AFL3-W15A-BT 的底部配有下列連接器與開關： 移除 & 裝回後蓋 移除 – 移除後蓋固定螺絲。將後蓋朝 I/O 面板的方向滑動，直到後蓋脫離機殼的鎖附機制。接著， 將後蓋往上翻起便可順利從機殼上移除後蓋。 裝回 – 將後面板朝頂部滑入，直到內部與外部的鎖附機制皆完全卡入。之後，再用先前移除的螺 絲固定後蓋。 安裝 mSATA 模組 & 硬碟 mSATA – 移除預先鎖在螺柱上供固定 PCIe Mini 卡的螺絲。將 mSATA 模組插入插槽內，並用 先前移除的螺絲固定 mSATA 模組。 HDD – 移除硬碟托架固定螺絲來移除托架。用 4 顆螺絲將硬碟固定在托架上。連接 SATA 傳輸線 與電源線。使用先前移除的螺絲將硬碟固定在機器上。...

  • Page 6: Specifications

    Specifications / 規格 LCD Size/尺寸 15.6" (16:9) Max. Resolution/最高解析度 1366 (W) x 768 (H) Brightness/亮度 400 cd/m Contrast Ratio/對比 700:1 LCD Color/顏色 262K Pixel Pitch/像素間距(mm) 0.240 (H) x 0.240 (V) Viewing Angle/可視角度 160° (H)/ 160°(V) Backlight/背光 LED backlight (MTBF: 50,000 hrs) Touchscreen/觸控螢幕...
  • Page 7 Software Driver / 驅動程式安裝 All the drivers for the AFL3-W15A-BT are on the utility CD that came with the system. The utility CD contains drivers for Windows 7 and Windows 8 operating systems. Please select the corresponding drivers for the system.

  • Page 8: Safety Instructions

    Headquarters America China 威強電工業電腦 IEI Integration Corp. 威强电工业电脑 IEI Integration (Shanghai) Corp. IEI Technology USA Corp. 上海市闵行莘庄工业区申富路 515 号 No. 29, ZhongXing Rd., Xizhi Dist., 138 University Parkway, Pomona, New Taipei City 221, Taiwan CA 91768, USA No. 515, Shen Fu Rd., Xin Zhuang Industrial Develop Zone,...
