Anti-draft Valve Assembly (67)
Figure 47
Reference
Number
1
2
3
4
5
6
7
8
9
S0709401K
Page 38
Description
Body
Poppet
Plug
Piston
Spool
Sleeve
Spring
Spring
O-ring
Reference
Description
Number
10
11
Backup Ring
12
Backup Ring
13
14
Plug Assembly
15
Plug Assembly
16
17
Main Control Valve (Kayaba)
O-ring
O-ring
Spring Seat
Steel Ball
