Daewoo Solar 225LC-V Shop Manual page 295

MODEL CYLINDER
ARM
S55-V SWING
BUCKET
ARM
S130LC-V
BOOM (OP)
BUCKET
ARM
S220LL
BOOM
BUCKET
Cylinders
øA øB
110 mm 69 mm
(4.33 in) (2.72 in) (0.47 in)
100 mm 58 mm
(3.94 in) (2.23 in) (0.47 in)
110 mm 69 mm
(4.33 in) (2.72 in) (0.39 in)
130 mm 90 mm
(5.12 in) (3.54 in) (0.47 in)
125 mm 85 mm
(4.92 in) (3.35 in) (0.47 in)
115 mm 75 mm
(4.53 in) (2.95 in) (0.47 in)
147 mm 107 mm
(5.79 in) (4.21 in) (0.47 in)
142 mm 102 mm
(5.59 in) (4.02 in) (0.47 in)
125 mm 102 mm
(4.92 in) (4.02 in) (0.43 in)
C D
S55-V (BOOM, BOOM {OPT})
12 mm 5 mm
S55-V PLUS (SWING)
(0.20 in)
S75-V (BUCKET)
12 mm 5 mm
(0.20 in)
S55-V PLUS (BUCKET)
10 mm 5 mm
S80W-II (DOZER)
(0.20 in)
MEGA 400 (P/S)
S130W-V (ARM (EURO))
S140W-V (ARM (EURO))
S160W-V (ARM)
S170LC-V (BOOM)
S170W-V (BOOM)
S180W-V (BOOM)
12 mm 5 mm S200W-V (BOOM)
(0.20 in) S200LC-V (BOOM)
S200N-V (BUCKET) (OPTION)
S210W-V (BOOM)
S220LC-V (BOOM)
S225LC-V (BOOM)
S225NLC-V (BOOM)
S225NLC-V (BUCKET) (OPTION)
S130W-V (ARM)
S130W-V (NEW BOOM)
S130LC-V (SHORT ARM)
S140W-V (ARM)
S140W-V (BOOM)
S140W-V (OUTRIGGER)
12 mm 5 mm
S160W-V (BOOM)
(0.20 in)
S160W-V (OUTRIGGER)
S170W-V (BUCKET)
S220LC-V (BUCKET)
S220LL (BUCKET)
S225LC-V (BUCKET)
S225NLC-V (BUCKET)
12 mm 5 mm S140W-V (BUCKET)
(0.20 in) S160W-V (BUCKET)
S330LC-V (ARM)
S340LC-V (ARM)
S370LC-V (ARM)
12 mm 5 mm
S400LC-V (BOOM, BUCKET)
(0.20 in)
S420LC-V (BOOM, BUCKET)
S450LC-V (BOOM, BUCKET)
S470LC-V (BOOM, BUCKET)
S200N-V (ARM (OP))
S225NLC-V (ARM (OP))
S210W-V (ARM)
12 mm 5 mm S220LC-V (ARM)
(0.20 in) S225LC-V (ARM)
S225NLC-V (ARM)
S290LC-V (BOOM)
S300LC-V (BOOM)
S170LC-V (BOOM)
11 mm 4.5 mm
S200W-V (BUCKET)
(0.18 in)
S210W-V (BUCKET)
MODEL (CYLINDER)
S0705000
