12. Remove two caps (1, Figure 4) from
counterweight (2).
13. Install two lifting eyes in lifting holes (3,
Figure 4).
Model
Solar 225LC-V
Solar 225NLC-V
Solar 255LC-V
Solar 300LC-V
Solar 300LL
Solar 340LC-V
Solar 420LC-V
Solar 470LC-V
14. Using a suitable lifting device capable of
handling load,
counterweight (2,
beginning to loosen four bolts (4). Stop
lifting with assist crane as soon as lifting
slings are taut.
15. Remove four bolts (4, Figure 4) and
washers/spacers (5) from counterweight
(2).
NOTE: Heat bolts if necessary, to free
them.
16. When bolts (4, Figure 4) and washers/
spacers (5) have been removed, lift
counterweight (2) a very short distance
above support frame (6) and stop. Check
slings and make sure counterweight is
being supported evenly.
S0403050K
Page 6
Return to Master Table of Contents
Lifting Eye Size
M48x5.0
partially support
Figure 4) before
1
3
3
6
5
4
Figure 4
2
BDS0220L
Counterweight
