OPERATING MANUAL BDC-99
VERSION 1.2
www.blastrac.com
1-800-256-3440

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BDC-99 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Blastrac BDC-99

Summary of Contents for Blastrac BDC-99

  • Page 1 OPERATING MANUAL BDC-99 VERSION 1.2 www.blastrac.com 1-800-256-3440...

  • Page 2: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY in accordance with Appendix II sub A of Directive 2006/42/EC BLASTRAC B.V. Utrechthaven 12 NL - 3433 PN NIEUWEGEIN Tel: 0031 (0)30 601 88 66 Fax: 0031 (0)30 601 83 33 Info@Blastrac.nl The Netherlands We declare under our sole responsibility that the machine as described below conforms with the Health and Safety requirements of the European Directive for machine Safety.

  • Page 3: Table Of Contents

    Table of contents EC Declaration of Conformity 1. Introduction 2. Machine description 3. Safety Safety precautions - general Safety precautions - with regard to transport Safety regulations – with regard to maintenance 4. Before operation Checkpoints of power supply 5. Operation Starting / stopping the machine Work with the machine Interrupting work...

  • Page 4: Introduction

    Class H13 HEPA filter in accordance with EN1822 Application The BDC-99 is especially designed to be used in combination with Blastrac machines. And can also be used with every other type of machine. Contact Blastrac B.V. for the correct execution and combinations.
  • Page 5 Dust bin kit Longo pack kit Big bag kit Rubber impact plate Manometer, shows the pressure of the air tank. The pulse to clean the filters must be given at 5 – 5.5 bar. Drain valve. Open regular to remove water from the air tank.

  • Page 6: Safety

    It should only be used for removing not-inflammable dust or substances.  The unit should not be used near flammable gasses or substances. The BDC-99 must not be applied for carcinogenic or asbestos substances.  Do not use the unit when it is damaged.
  • Page 7 Safety regulations The following sticker is placed on the machine. Meanings of these symbols are: Ear protection is obliged  Safety glasses with lateral protection are obliged  CE-mark on this machine  Safety shoes obliged  Consult the manual before operating the machine ...

  • Page 8: Before Operation

    4. Before operation Before using the machine it is essential to inspect the machine. It is not permitted to use the machine if the machine safety is not according the checkpoints below. Checkpoints of electrical safety Use only extension cables for extending the main cable that are sized and marked in accordance with ...

  • Page 9: Maintenance

    Store the cleaned and dry machine in a dry and humid free room. Protect the electrical motors from moisture, heat, dust and shocks. All repair work must to be done by qualified Blastrac personnel, this to guarantee a safe and reliable machine. Any guarantee on the machine is expired when: Non original Blastrac parts have been used ...

  • Page 10: Filter Replacement

    When there is pressure but the pulse system does not function, there might be a problem in the electrical system which controls the pulsing system. Check the wiring and the PLC-settings. Advised is to take contact with Blastrac Support in order to prevent operational problems. Compressor Replacement or cleaning of the air filter of the compressor (item 11 page 5) is depending on the environment in which the dust collector is operating.

  • Page 11: Special Option

    7. Special option For request we have got advanced option for work were is necessary to use special equipment. 7.1 Hepa filter Task of this option is keep more clean air at work by the use of high class hepa filter. Applied by us filters have high filtration efficiency starting from just 99,95%.

  • Page 12: Technical Data

    66 mbar Ø127mm / Ø150 mm Dust hose connection 150L Dust bin capacity Longo pack capacity 67,5L / 145L Dust bag 1731mm Length 866mm Width 1643mm Height 520kg Weight Design and specifications are subject to change without notice by Blastrac B.V.

  • Page 13: Contact

    13201 North Santa Fe Avenue  Oklahoma City, OK 73114  Ph: 800-256-3440  F: 405-478-8608 blastrac.com Product Warranty Standard Equipment Products: Blastrac warrants its Blastrac Standard Equipment Products against defects in quality of material and workmanship, under normal and proper use for a period of 1 Year from the date of delivery, as noted on the returned warranty registration card, or, in the case of Rental Fleet Machines, 180 Days from the date of assignment to Rental Fleet.
  • Page 14 Blastrac Returned Merchandise Authorization (RMA) Form. Blastrac will then send the RMA form to the customer authorizing the return of the parts for warranty evaluation. The parts must be received within sixty (60) days following the RMA origination date or the warranty claim will be denied.
  • Page 15 ® the information recorded here by registering online at blastrac.com, or complete this page and fax to 866-485-1046, or if you prefer, detach and mail to: Blastrac, 13201 North Santa Fe Avenue, Oklahoma City, OK 73114-9901...
  • Page 16 Blastrac 13201 North Santa Fe Avenue Oklahoma City, OK 73114 800-256-3440 Fax: 866-485-1046 www.blastrac.com...
