Summary of Contents for Blastrac BDC-66
- Page 1 SERVICE MANUAL BDC-66 VERSION 1.4 www.blastrac.com 1-800-256-3440...
- Page 2 EC DECLARATION OF CONFORMITY in accordance with Appendix II sub A of Directive 2006/42/EC BLASTRAC B.V. Utrechthaven 12 NL - 3433 PN NIEUWEGEIN Tel: 0031 (0)30 601 88 66 Fax: 0031 (0)30 601 83 33 Info@Blastrac.nl The Netherlands Declare under our sole responsibility that the machine as described below conforms with the Health and Safety requirements of the European Directive of the machine Safety.
- Page 3 Index 1. Spare parts Contact...
-
Page 4: Spare Parts
1. Spare parts Fig. 01... - Page 5 Fig. 01 Item Part number Description Qty. E09751 Filter house E09772 Back legs bottom bracket E09773 Back legs upper bracket E09754 Handle E07763 Divider E03466 Rubber distance E09755 Pulse tube E09756 Top cover E09778 Rubber impact plate E09757 Filters secure plate E09758 Filter bracket E10218...
- Page 6 Fig. 02...
- Page 7 Fig. 02 Item Part number Description Qty. E06933 Compressor 999-9107 Shock absorber A40-30 E09790 Water separator mounting plate E07756 Protection pulse valve E07554 Pulse valve system E14003 Mini ball valve 1/4" m/f bsp E06923 Adaptor knee 10mm x 1/4" mbsp, swivel DA--9290.1 Airpistol DA--9290.2...
- Page 8 Fig. 03...
- Page 9 Fig. 03 Item Part number Description Remarks Qty. E06989 Fan housing E06954 Fan impeller type 1 E06965 Fan hub E07059 Motor mounting bracket E07594 BU fan unit (set) E07067 Tension plate DG14 Motor pulley 50Hz E07071 Motor pulley 60Hz E07071 Motor pulley E06131 V-belt...
- Page 10 Fig. 04...
- Page 11 Fig. 04 Item Part number Description Qty. E09787 Bottom plate E06311 Dust bag 70ltr E09418 Dust bag 145ltr E09788 Big bag adapter E04623 Valve plate E04624 Rubber plate valve E09789 Valve handle --------- Knob M8 E04622 Valve axle BE0630 Linch pin E07655 Longo pack - bag bracket E08500...
- Page 12 Fig. 05 Item Part number Description Qty. E09793 Front cover E09977 Hepa filter class H13 E09795 Hepa filter class H14 E09792 Back cover E09794 Adapter E11000 Bracket E11001 Hole plug E11002 Plate Hose Ø125 E11003 Adhesive rubber seal Fig. 06 Fig.
-
Page 13: Product Warranty
13201 North Santa Fe Avenue Oklahoma City, OK 73114 Ph: 800-256-3440 F: 405-478-8608 blastrac.com Product Warranty Standard Equipment Products: Blastrac warrants its Blastrac Standard Equipment Products against defects in quality of material and workmanship, under normal and proper use for a period of 1 Year from the date of delivery, as noted on the returned warranty registration card, or, in the case of Rental Fleet Machines, 180 Days from the date of assignment to Rental Fleet. - Page 14 Blastrac Returned Merchandise Authorization (RMA) Form. Blastrac will then send the RMA form to the customer authorizing the return of the parts for warranty evaluation. The parts must be received within sixty (60) days following the RMA origination date or the warranty claim will be denied.
- Page 15 ® the information recorded here by registering online at blastrac.com, or complete this page and fax to 866-485-1046, or if you prefer, detach and mail to: Blastrac, 13201 North Santa Fe Avenue, Oklahoma City, OK 73114-9901...
- Page 16 Blastrac 13201 North Santa Fe Avenue Oklahoma City, OK 73114 800-256-3440 Fax: 866-485-1046 www.blastrac.com...
