Summary of Contents for Southern Enterprises MS040100TX
- Page 1 MS040100TX Marcell Media Console For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seifurniturestore.com PO#: Page | 1...
-
Page 2: Parts List
Marcell Media Console Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or a blanket. Check that you have all parts indicated. Call customer service if any hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. - Page 3 Quantity Quantity Quantity of 27 Screw Dia. 1/8” x 1/2”L Magnet Knob Quantity Quantity Quantity of 4 of 2 of 2 Bolts Dia. 5/32”x 1/2”L Magnet Plate Screw Dia 1/8” x 1/2”L Quantity Quantity Quantity of 4 of 32 of 8 Hinge Screw Dia 1/8”...
- Page 4 Marcell Media Console Assembly Instructions Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Side Panels (2/3). Screw Cam Bolts (A) into threaded holes Do not overtighten cam bolts. Stop when they feel secure. on Front Panels (4/5). Attach Front Panels (4/5) to Side Panels (2/3) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until...
- Page 5 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Shelf Panel (6). Screw Cam Bolts (A) into threaded holes on Side Panels (2/3). Attach Side Panel (2/3) to Shelf Panel (6) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
- Page 6 Align Cam Bolts (A) by hand. Insert Cam Locks (B) into corresponding holes on Side Panels (2/3). Screw Cam Bolts (A) into threaded holes on Top Panel (1). Attach Top Panel (1) to Side Panels (2/3) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
- Page 7 Align Screws (K) by hand. Attach Hinges (J), to Side panels (2/3) and Doors (10/11) with Screws (K). Tighten Screws (K) with Phillips screwdriver (not included). Attach Magnet Plates (H) to Doors (10/11) with Screws (I). Tighten Screws (I) with Phillips screwdriver (not included).
- Page 8 Insert Adjustable Shelf Panels (12) in the direction the arrows indicate. Ensure the Shelf Pins (L) are securely holding the Adjustable Shelf Panels (12). Figure 8 Now your Marcell Media Console is ready to use! Figure 9 Page | 8...
-
Page 9: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 10 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the media stand. Model: MS040100TX Marcell Media Console Southern Enterprises, Inc 600 Freeport Parkway,...
