- Page 1 MS998700TX Kendleton TV/ Media Console For assistance with assembly contact: ASSEMBLY INSTRUCTION Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#：...
-
Page 2: Parts List
MS998700TX Kendleton TV/Media Console Parts list Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the diagrams below. - Page 3 Quantity Quantity Quantity of 2 of 12 of 12 Ball bearing slide Cam bolt Cam lock Quantity Quantity Quantity Quantity of 18 of 12 of 4 of 6 Wood Dowel Bolt Bolt :Dia1/4”x5/8”L Bolt: Dia. 1/4”x1-1/2”L Dia5/16”x1-3/16”L Dia1/4”x1-5/8” Quantity Quantity Quantity Quantity of 7...
- Page 4 MS998700TX Kendleon TV/Media Console Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page Attach ball bearing slide (1) on left side panel (C) & vertical panel (D) with screw (9), Tighten with a Philips screwdriver (not included)
- Page 5 Insert cam lock (3) into predrilled holes on pre-assembled unit in figure 2. Screw cam bolt (2) into pre-drilled holes on top panel (A). Attach top panel (A) to pre-assembled unit in figure 2 by inserting wood dowel (4) & cam bolt (2) into corresponding pre-drilled holes until top panel (A) &...
- Page 6 Insert cam lock (3) into predrilled holes on left side panel (C). Screw cam bolt (2) into pre-drilled holes on pre-assembled unit in figure 5. Attach left side panel (C) to pre-assembled unit in figure 5 by inserting wood dowel (4) & cam bolt (2) into corresponding pre-drilled holes until left side panel (C) &...
- Page 7 Attach leg (P) to pre-assembled unit in figure 8 with bolt (5) Attach middle pre-assembled unit in figure 8 with bolt (18) Attach leveler (13) to leg(P)& middle leg (R ) by hand. Tighten bolt with Allen wrench ( 14) Figure 9 Attach right drawer side panel (M) &...
- Page 8 Insert cam lock (3) into predrilled holes on pre-assembled unit in figure 11. Screw cam bolt (2) into pre-drilled holes on drawer front panel (K). Attach drawer front panel (K) to pre-assembled unit in figure 11 by inserting cam bolt (2) into corresponding pre-drilled holes until drawer front panel (K) &...
- Page 9 Attach back holder (16) to pre-assembled unit in figure 13 using screw (10) and tighten using Philips screwdriver. Figure 14 Attach the ball bearing slide (1) on left drawer side panel (L) and right drawer side panel (M) with screw (9), Tighten screw by using Philips screwdriver.
-
Page 10: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 11 This unit contains a permanent warning sticker located on back panel. Do not allow children under 16 years to move the cart. Model: MS998700TX Kendleton TV/Media Console Southern Enterprises, Inc 600 Freeport Parkway, Suite 200 Coppell, Texas, 75019...
