- Page 1 MS333400TX –ESPRESSO LADDER MEDIA STAND For assistance with assembly contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#12877...
- Page 2 LADDER MEDIA STAND Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below.
- Page 3 Quantity Quantity of 1 of 1 Top Shelf Panel Medium Shelf Panel Quantity Quantity of 1 of 2 Bottom Shelf Panel Drawer Front Quantity Quantity of 2 of 2 Drawer Left Side Panel Drawer Right Side Panel Quantity Quantity of 2 of 2 Drawer Back Panel Drawer Bottom Panel...
- Page 4 Quantity Quantity of 20 Of 20 Cam Bolt Cam Lock Quantity Quantity of 36 Of 4 Φ8mm*1-3/16” Φ8mm*1” Wood Dowel Wood Dowel Quantity Quantity of 10 Of 10 Φ1/4”*1” Spring Washer Hexagon Head Bolt Quantity Quantity of 10 Of 1 Allen Wrench Flat Washer (10)
- Page 5 (15) (16) Quantity Quantity of 12 of 36 Φ8*Φ4mm*7/16” Screw Angle Iron (17) (18) Quantity Quantity of 24 of 6 Sticker Wooden Plug (19) (20) Quantity Quantity of 4 of 2 Anti-Tip Iron Plastic Strip (21) (22) Quantity Quantity of 2 of 2 Φ8*Φ4mm*9/16”...
- Page 6 LADDER MEDIA STAND Assembly Instructions ( 1) ( 2) Insert cam lock (2) into pre-drilled holes on top center panel (F). Screw cam bolt (1) into pre-drilled holes on "Please do not over tighten cam bolts. shelf panel (B). Please stop when you feel tight" Attach top center panel (F) to shelf panel (B) by inserting wood dowel (3) &...
- Page 7 Insert cam lock (2) into pre-drilled holes on pre-assembled unit in figure 3. Screw cam bolt (1) into pre-drilled holes on top panel (A). Attach top panel (A) to right side panel (E) ,top center panel (F) and left side panel (D) by inserting wood dowel (3) &...
- Page 8 Attach bottom left post (I) to left side panel (D) by using hexagon head bolt (5) ,spring washer (6) and flat washer (7). Tighten with Allen wrench (8) . Cover hexagon head bolt (5) with sticker (17). Figure 7 Attach bottom right post (J) to right side panel (E) by using hexagon head bolt (5) ,spring washer (6) and flat washer (7) .
- Page 9 Attach top right post (L) to top shelf panel (M), medium shelf panel (N) and bottom shelf panel (O) by using hexagon head bolt (5) ,spring washer (6) and flat washer (7) . Tighten with Allen wrench (8) . Cover hexagon head bolt (5) with wooden plug (18).
- Page 10 Join drawer front (P) to drawer left side panel (Q) by using wood dowel (12) and screw (11), tighten by screw driver. Join drawer back panel (S) to drawer left side panel (Q) by using wood dowel (12) and screw (11), tighten by screw driver. Insert bottom panel (T) to drawer front (P) and drawer back panel (S).
- Page 11 Attach anti-tip iron (19) to the back of top panel (A) with short screw (21). Tighten with screw driver. Mark two desired locations on wall. Drill two 3/16" holes on wall. Insert plastic anchors (22) into the 2 holes on wall as shown.
- Page 12 Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
- Page 13 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: MS333400TX Ladder Media Stand Southern Enterprises, Inc 600 Freeport Parkway,...
