- Page 1 MS040500TX Fortenbury Media Console For assistance with assembly, contact: Southern Enterprises, Inc. Customer Service: 1-800-633-5096 Assembly Instructions service@seidal.com www.seifurniturestore.com PO#: Page | 1...
- Page 2 Fortenbury Media Console Parts List Please check packaging for all parts and hardware before discarding. Before beginning assembly, separate each type of hardware. Carefully study the diagrams below and check that you have all parts indicated. Call Customer Service if missing any hardware. Using the incorrect hardware will cause damage. Quantity Quantity Quantity...
- Page 3 Quantity Quantity Quantity of 2 of 2 of 1 Small Drawer Back Panel Small Drawer Bottom Panel Big Drawer Front Panel Quantity Quantity Quantity of 1 of 1 of 1 Big Drawer Back Panel Big Drawer Bottom Panel Back Panel Quantity Quantity Quantity...
- Page 4 Quantity Quantity Quantity of 12 of 3 of 3 Bolts Cam Locks Knob Dia. 5/32”x 3/4”L Quantity Quantity Quantity of 16 of 12 of 2 Screw Dia. 5/32” x 1L Cotton Mat Anti-tipping hardware Care and Cleaning Instructions: Before using, wipe with a clean, dry cloth. For replacement parts or questions, please call Periodically apply furniture wax to renew the SEI Customer Service at 1-800-633-5096.
- Page 5 Fortenbury Media Console Assembly Instructions Attach Upper shelf Panel (4) to Middle Panels (5) with Screws (M) and Wood Dowels (C). Tighten Screws (M) with Phillips screwdriver (not included). Figure 1 Insert Cam Locks (B) into corresponding holes on pre-assembled unit from Figure Please do not overtighten cam locks.
- Page 6 Attach Lower Shelf Panel (8) to Back Vertical Panel (7) by using Wood Dowels (C) as shown in Figure 3. Figure 3 Insert Cam Locks (B) into corresponding holes on pre-assembled unit from Figure Screw Cam Bolts (A) into threaded holes on Front Vertical Panel (6).
- Page 7 Insert Cam Locks (B) into corresponding holes on pre-assembled unit from Figure Screw Cam Bolts (A) into threaded holes on Side Panels (2/3). Attach Side Panels (2/3) to pre-assembled unit from Figure 4 by inserting Cam Bolts (A) into corresponding holes until all panels meet.
- Page 8 Insert Cam Locks (B) into corresponding holes on pre-assembled unit from Figure Screw Cam Bolts (A) into threaded holes on Top Panel (1). Attach Top Panel (1) to Side Panels (2/3) and Middle Panel (5) by inserting Cam Bolts (A) and Wood Dowels (C) into corresponding holes until all panels meet.
- Page 9 Insert Cam Locks (J) into corresponding holes on Drawer Side Panels (11/12). Screw Cam Bolts (I) into threaded holes on Drawer front (10). Attach Drawer Front (10) to Drawer Side Panels (11/12) by inserting Cam Bolts (I) into corresponding holes until all panels meet.
- Page 10 Insert Cam Locks (J) into corresponding holes on Drawer Side Panels (11/12). Screw Cam Bolts (I) into threaded holes on Drawer front (15). Attach Drawer Front (15) to Drawer Side Panels (11/12) by inserting Cam Bolts (I) into corresponding holes until all panels meet.
- Page 11 Insert drawer into assembled unit. Make sure drawers glide smoothly in and out. Note: There is a lever located on male slide for bottom drawer slide. Push lever to either side in order to detach male slide from female slide. Figure 11 Attach Brackets (O) to Back Panel using Screws (O).
- Page 12 Now your Fortenbury Media Console is ready to use! Figure 13 Page | 12...
-
Page 13: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas), Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
