- Page 1 MS163200TX Kylan Media Tower For assistance with assembly, contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#: Page | 1...
- Page 2 Kylan Media Tower Assembly Instructions Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 1 of 1 of 1 Back Panel Drawer Back Panel Drawer Bottom Panel Quantity Quantity Quantity of 20 of 20 of 16 Cam Lock Wood Dowel Ø 8 x 30mm Cam Bolt Quantity Quantity Quantity of 35 of 2 of 22 Round Head Screw...
- Page 4 Quantity Quantity Quantity of 1 of 1 of 6 Female Slide Right Screw Ø 1/8” x 1”L Male Slide Left Quantity Quantity Quantity of 2 of 12 of 4 Screw Shelf Pin Ø 1/8” x 1-5/8”L Magnet Plate Quantity Quantity Quantity of 4 of 4...
- Page 5 Kylan Media Tower Assembly Instructions Screw with fingers to help align screws before using screwdriver. Attach Female Slide Left (11) to Left Side Panel (C) using Flat Head Screws (4). Tighten Flat Head Screws (4) with Phillips screwdriver. Figure 1 Attach Female Slide Right (12) to Right Side Panel (D) using Flat Head Screws (4).
- Page 6 Screw with fingers to help align cam bolts before using screwdriver. Insert Cam Locks (2) into corresponding holes on Bottom Panel (B), Fixed Shelf Panel (E), Front Crosspiece (G) and Back Crosspiece (H) Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Right Side Panel (D) and Left Side Panel (C).
- Page 7 Insert Cam Locks (2) into corresponding holes on assembled unit from Figure 3 Screw Cam Bolts (1) and insert Wood Dowels (3) into corresponding holes on Top Panel (A). Attach Top Panel (A) to assembled unit by inserting Wood Dowels (3) and Cam Bolts (1) into corresponding holes until Top Panel (A) and the assembled unit from Figure 3 meet.
- Page 8 Attach Male Slide Left (13) to Drawer Left Panel (K) using Flat Head Screws (4). Attach Male Slide Right (14) to Drawer Right Panel (L) using Flat Head Screws (4). Tighten Flat Head Screws (4) with Phillips screwdriver. Figure 6 Insert Cam Locks (2) into corresponding holes on Drawer Side Panel (K) (L) Screw Cam Bolts (1) into corresponding...
- Page 9 Insert Drawer Bottom Panel (N) into the grooves of assembled unit from Figure Figure 7 Attach Drawer Back Panel (M) to the assembled unit from Figure 7 using Screws (15). Tighten Screws (15) with Phillips screwdriver. Figure 8 Page | 9...
- Page 10 Cover Cam Locks with Cover (23) as shown. Insert drawer into assembled unit. Figure 9 Attach the Metal Plate (16) on the inner inside of the Door (F) using Flat Head Screws (4) Attach the Hinges (7) to the Door (F) using Flat Head Screws (4) Tighten Flat Head Screws (4) with Phillips screwdriver.
- Page 11 Attach the Door (F) to the unit from using Flat Head Screws (4) Tighten Flat Head Screws (4) with Phillips screwdriver. Figure 11 Insert Shelf Pins (17) into holes on Right Side Panel and Left Side Panel. Figure 12 Page | 11...
- Page 12 Insert Adjustable Shelf Panel (I) in the arrows direction. Make sure the shelf pins stably hold the Shelves (I). Figure 13 Attach Brackets (20) to back panel using Screws (19). Tighten Screws (19) using Philips screwdriver. Mark two desired locations on wall and drill two 3/16"...
- Page 13 Move this item close to the wall Brackets (20) and tie in all Brackets (20) together with Plastic Straps (22) as shown in diagram. Anti-tipping hardware must be used for this product to avoid tipping and injury. Figure 15 Now your Kylan Media Tower is ready for use.
-
Page 14: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas) Mon-Fri 9am – 4pm CST, or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
