- Page 1 MS998400TX For assistance with assembly contact: Landis TV/Media Console Southern Enterprises, Inc. customer service 1-800-633-5096 Assembly Instructions www.seidal.com service@seidal.com PO#： Page 1...
- Page 2 Landis TV/Media Console Parts list Please review all parts and hardware before disposing of any packaging. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity Quantity Quantity of 28 of 25 of 2 round head screw: Dia 1/8” x short screw: Dia 1/8” x 1/2”L 1/2”L handle Quantity Quantity Quantity of 4 of 2 of 8 small bolt wall bracket shelf pin Quantity Quantity Quantity of 4 of 4...
- Page 4 Landis TV/Media Console Assembly Instructions Insert cam locks (3) into holes on vertical panel (F). Screw cam bolts (2) into holes on fixed shelf panel (B). Attach vertical panel (F) to fixed shelf panel (B) by inserting wood dowels (1) and cam bolts (2) into corresponding holes until vertical panel (F) and fixed shelf panel (B) meet.
- Page 5 Insert cam locks (3) into holes on pre-assembled unit as shown. Screw cam bolts (2) into holes on the underside of top panel (A). Attach pre-assembled unit to top panel (A) by inserting wood dowels (1) and cam bolts (2) into corresponding pre-drilled holes until pre-assembled unit and top panel (A) meet.
- Page 6 Attach hinges (4) to pre-assembled unit, left door (G), and right door (H) with screws(5) Tighten screw with phillips screwdriver. Attach handles (7) to doors using small bolts (8). Attach magnets (14) to vertical panel (F) with screws (6). 14 14 Tighten screws and small bolts with Phillips screwdriver.
- Page 7 Attach wall brackets (9) to back panel using screws (13) and tighten wall screws using phillips screwdriver. Mark two desired locations on the wall and drill two 3/16" holes. Insert plastic anchors (11) into the two holes on wall as shown. You will need a hammer to help you.
-
Page 8: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 9 This unit contains a permanent warning sticker located on back panel. Do not allow children under 16 years to move the cart. Model: MS998400TX Landis TV/Media Console Southern Enterprises, Inc...
