- Page 1 MS990400TX - MULTICOLOR APOTHECARY CONSOLE/TV STAND For assistance with assembly contact: Southern Enterprises, Inc. ASSEMBLY INSTRUCTIONS Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#:...
-
Page 2: Parts List
MULTICOLOR APOTHECARY CONSOLE/TV STAND Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below. You may receive extra hardware with your unit. - Page 3 Quantity of 21 Quantity of 8 Quantity of 4 Screw ∮3x12 mm Shelf Holder Screw∮4x25 Quantity of 2 Quantity of 2 Quantity of 2 Door Catch Door Catcher Tilting prevent screw Quantity of 4 Adhesive Pad Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
- Page 4 MULTICOLOR APOTHECARY CONSOLE/TV STAND Assembly Instructions Assembly Instructions: Figure 1 Wood may scratch easily. Be careful ( 1 ) ( 2 ) when assembling. Do not scratch. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated Please do not over tighten cam bolts.
- Page 5 Figure 3 3. Attach wood Top (A) to Left / Right side panel(B/C) and Across Panel (G) by using cam bolt (1), cam lock (2) and Adhesive Pad (13) and wood Dowel(6) and Screw (9)as shown. Figure 4 4. Attach back panel (L) to the back of frame by using screw (7) as shown.
- Page 6 Figure 5 5. Attach left door (H) and right door (I) to the frame by using hinge (4) and screw (5) as shown. Then attach door catch (10) to the top of frame by using screw (7), attach door catcher (11) by using screw (3) as shown.
- Page 7 Figure 7 Attach Tilting prevent screw （12） to Back Panels using Screws. Tighten screws using Philips screwdriver. Mark two desired locations on wall. Drill two 3/16" holes on wall. Insert plastic anchors into the 2 holes in wall as shown. Hammer plastic anchor into wall.) Attach the Tilting prevent screw（12）...
-
Page 8: Parts Replacement Form
90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts. - Page 9 This unit contains a permanent warning sticker located on under side of top shelf or inside drawer. Do not allow children under 16 years to move the cart. Model: MS990400TX MULTICOLOR APOTHECARY CONSOLE/TV STAND Southern Enterprises, Inc...
