Tab. 2: All data objects
Name
No.
Device identifier
0
Status
1
All the data objects that can be cyclically transmitted are described below.
Type
Description
UINT32
Byte 0+1
Byte 2
Byte 3
UINT32
bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
24
27
= 0x1180
Identification number
= 0x50
ProMinent identifier for pump
product group
= 8
"DULCO flex Control" pump family
Name
Function
Motor
0 – Motor idle
-
Mode
00 – halt
01 – manual
02 – batch
Error
There are errors, see "Errors"
Warnings
There are warnings, see "Warn‐
ings"
Manual stop
Pump has been stopped manually
Stop
Pump has stopped
Priming
Pump is in priming mode (higher-
level function)
Auxiliary
Pump is in auxiliary mode (higher-
level function)
Pause
Pump has been switched to pause
(higher-level function)
Module
Fieldbus mode active
Hose change
Hose is being changed
Batch Mem.
Batch memory is activated
Calibrated
Pump is calibrated
Relay 1
Relay 1 physically exists
Relay 2
Relay 2 physically exists
AnalogOut
Module physically exists
Hose rupture
Hose rupture sensor is installed
Actual direction
0 = clockwise
of rotation
1 = counter-clockwise
The user should stop the pump
and wait for the release to change
the direction of rotation (Bit #21 in
the status). Only then can the
direction of rotation be reversed.
Direction of
Release for change of direction of
rotation
rotation
-
-
-
-
-
-
Operation
1 – Motor run‐
ning
-
03 – contact
04 - analog
9
