Fabia II 2007 ➤ , Fabia II 2009 ➤ , Fabia II 2011 ➤
Heating, Air conditioning - Edition 06.2013
10 Climatic, air conditioning system with
manual control
Note
Comply with the safety measures when working on vehicles
♦
with air conditioning system and when using refrigerant R
134a and observe the instructions for working on the refriger-
ant circuit ⇒ Air conditioning system with refrigerant R134a;
Rep. gr. 00 technical data.
As of CW 46.10, the temperature in the vehicle interior is con-
♦
trolled manually. As of this date, some temperature senders
are no longer fitted, see
At first glance, the manual air-conditioning unit of the semi-
♦
automatic air conditioning system can be identified on its
operating unit for air conditioning system, which has no nu-
merical value of the set interior temperature.
Detailed description of the function of the air conditioning sys-
♦
tem ⇒ Owner's manual Fabia II (depending on the model
year).
⇒ "10.1 Summary of components - interior", page 70
⇒ "10.2 Summary of components - Heating and air conditioning
unit", page 73
⇒ "10.3 Dismantling and assembling heater and air conditioning
unit", page 75
⇒ "10.4 Expansion valve - Summary of components", page 77
⇒ "10.5 Removing and installing evaporator", page 77
⇒ "10.6 Control for heating and air conditioning system",
page 79
⇒ "10.7 Removing and installing flex shaft for positioning unit of
air distribution flaps", page 81
⇒ "10.8 Removing and installing control motor of fresh air flap and
re-circulating air flap V154 ", page 82
⇒ "10.9 Removing and installing the control motor of temperature
flap V68 ", page 82
10.1 Summary of components - interior
Note
The parts marked with an * must only be repaired in specialist service centres which have suitably trained
personnel and are fitted out for working on the refrigerant circuit.
70
⇒ page 73 .
