Exploranium KT-9 User Manual page 73

The procedure for running the S
1 Connect the supplied cable (Part no. 97945) to the KT-9
computer port located on the bottom panel (covering the
battery compartment).
2 Connect the other end of the cable to the
of your computer. Please note that the cable has a DB-9
connector. If your computer has the older 25-pin ports you
will either need a DB-9 to DB-25 adaptor or ask EXPLO-
RANIUM for a special DB-25 version of the connector cable.
3 Turn on the KT-9.
4 Select either the N
modes.
5 Erase all old data in the KT-9's memory.
6 Run the S
TICK
follows and is shown in Figure 21:
G:\XPLRANUM>scan7
*** SCAN MODE OF KAPPAMETER KT-9 ***
CONNECT KT-9 TO COM1 OF PC-COMPUTER
SWITCH KT-9 ON
SELECT MEASURING MODE 'nP' OR 'Cor'
ERASE ALL DATA FROM MEMORY OF KT-9 - press ENTER on PC
*** KT-9 READY ***
Enter name of file DEV:FILENAME.EXT
File mydata.dat opened for input
Enter HEADER of measurement
Figure 21 Sample session using the S
a) You will be reminded to connect the KT-9 to the com-
puter, turn on the KT-9, select either the N
program is as follows:
TICK
-P (nP) or C
O IN
program on your computer. A typical session
mydata.dat
FIRST Measurement
1: serial port
COM
(Cor) measuring
ORE
program
TICK
-P
O IN
65
or C
ORE
