58
7 — PC recording of data from a manually op-
SCAN C
• power the KT-9 on
• use any mode of operation
• ensure that any data in memory is erased (see "Clearing
the memory" on page 37)
K
5 Press the key to continue when you are ready.
6 You will be prompted to provide a filename where the col-
lected data will be stored:
Enter the name of file...
7 You will then be prompted to take a measurement with
the KT-9 (see "Taking measurements" on page 19).
Š
8 Press the key to exit the program.
c
9 Press the key on the computer. This opens a memory
buffer in the PC.
DISPLAY OF KT-9 MUST BE 'C
PRESS 'R' ON PC TO START SCAN MODE >>
You now have 10 seconds to begin the scan, otherwise the
computer will time out and display:
End of 10 sec TIMEOUT
You will then be presented with the clear prompt and have
to start again:
Press "C" ON PC TO CLEAR >>
10 Place the sensor against the object to be scanned.
11 To begin scanning, press the
be beeping and the data is displayed on the PC screen as it
is being stored in memory.
12 To stop recording, press the
13 Your data will be stored as ASCII text in the filename that
you specified in step 6.
0'
r
key. The KT-9 should now
c
key.
