Displays - Exploranium KT-9 User Manual

Displays

The characters that the KT-9 displays are summarized as follows
Character(s)
A:
C:
Cor:
Cdd:
d:
External Coil
EC:
ErrX
F:
o:
P:
nP:
Meaning Description
Access: Indicates the mode of mea-
surement can be set
Control: Indicates that you can change
from right-handed to left-
handed operation
Core: The measurement mode is set
for
CORE
Core Core sample measurement set
Diameter:
for a diameter of "dd" cm
Diameter: Core diameter in centimetres
An external coil is connected
and will be used
Error: Error number "X" occurred.
See "Error messages" on
page 38.
Full: The data memory is full, i.e. ten
readings have been stored
Average: The displayed value is the aver-
age of all the data in memory
Pin: The measurement mode is set
for the
No-Pin: The measurement mode is set
for operation without the pin
in place
9
samples
mode
PIN
