Simplex 4100ES Owner's Manual page 58

Adding and Removing Item to and from Install Mode, Continued
Adding and Removing Lists from Install Mode:
Adding and
Note: For information on making lists refer to the ES Panel Programmer's Manual (574-849).
Removing Lists
1. Press on the 9 button to access the lists.
2. Enter the Number of the list you want to move.
3. Press Enter
4. Once the Item appears on the display:
Once the action has been confirmed the following screen will appear.
Adding a group of points that raise the same Trouble to Install mode:
Adding and
1. Press on the Menu button.
removing groups to
Install Mode
2. Use the Arrows to Scroll to the Diagnostic Function option.
3. Press Enter.
4. From that menu, use the arrows to scroll down to the "View/Change Install Mode List" option.
5. Press Enter.
6. From "View Change Install Mode List" use the arrows to scroll down and select the group of
7. Select the group and press Enter to add them to Install Mode.
Removing a group of points from Install Mode:
1. Press on the Menu button.
2. Use the Arrows to Scroll to the Diagnostic Function option.
3. Press Enter.
4. From that menu, use the arrows to scroll down to the "View/Change Install Mode List" option.
5. Press Enter.
6. From "View Change Install Mode List" use the arrows to scroll down and select either:
•Press 1 to move the List to Install Mode
•Press 2 to remove the List from Install Mode.
Please stand by...
M1-6 Will Enable in 60 seconds
IMPORTANT: An Alarm could be reported after removing a
List or a Card from the Install Mode List (without warning).
Troubles you want moved to Install Mode. For Example:
Move NO ANSWER devices to Install mode?
•"Remove ALL NORMAL pts from Install Mode"
•"Remove ALL POINTS from Install Mode". Choosing this option makes the following
screen appear:
Please stand by...
M1-6 Will Enable in 60 seconds
IMPORTANT: Active Alarms can initiate without warning after the 60 second
countdown.
firealarmresources.com
7-4
