VPro BF Instruction Manual

Please read this manual before installation and use.
GENERAL
It composed of flange-end ball valve and high-power electric
actuator. (proportional control)
Actuator
AEX : For AC power.
Valve
BF type For various fluids and general use.
V type For control
L2 type For mixing / dividing.
PRODUCT CODE
BF type (JIS 10K)
(JIS 20K)
V type (JIS 10K)
(JIS 20K)
L2 type
(1) Actuator
AEX
(2) Valve
BF V-
L2
(3) Voltage
1 : 100 / 110 V AC
2 : 200 / 220 V AC
(4) Sizing code
0 : Standard
1 : Light
2 : Heavy
Instruction manual
Electric Actuated Ball Valve
It corresponds to various control
input signals.
A E X B F 1
A E X B F 3 T T
A E X V - 1
A E X V - 3
A E X L 2 1
(1) (2) (3) (4) (5) (6) (7) (8)
(5) Connection
1 : JIS 10K
3 : JIS 20K
(6) Body material
D : FCD400 / FCD-S
T : SCS13A / SCS13
U : SCS14A / SCS14
W : SCS16A
(7) Ball material
T : SCS13A / SUS304
U : SCS14A / SUS316 / SCS11
W : SCS16A / SUS316L
BF L2 V
- -
- -
U - -
U - -
G - -
(9) (10)
(8) Seat material
T : N-PTFE
G : R-PTFE
R : R-PTFE (with metal-ring)
S : Thin seat
M : Solid seat
(9) Size [mm]
ex. 25 A ® 025
(10) Option
L
EA : Alarm output board
EI : 4 to 20 mA
(11) Operation mode
Nil : Mode A
1/11
OSVBF225-EN
BF V
-
-
-
-
-
(11)
: Auxiliary limit switch
indication signal board
J : Mode B
SP-1474
L2
