VPro PND-03S Instruction Manual

Please read this manual before installation and use.
GENERAL
It is small, light weight and economical butterfly valve.
Actuator
Double-acting type
PND
TAD
Single-acting type
PSO (Airless SHUT)
TAO (Airless SHUT)
PSC (Airless OPEN)
TAC (Airless OPEN)
Valve
Z type This type designed for 3 piece structure
and it is easy to maintenance.
PRODUCT CODE
Z type Threaded End Rc
Socket End
(1) Actuator
PND TAD
PSO TAO
PSC TAC
(2) Valve
Z-
(3) Voltage
9 : Air
(4) Sizing code
0 : Standard
1 : Light
2 : Heavy
(5) Connection
5 : Threaded End Rc
7 : Socket End
Instruction manual
Pneumatic Actuated Butterfly Valve Z
(PVC)
(C-PVC)
(1)
(6) Body material (10) Option
T : SCS13A
(7) Cap / Socket
U : SCS14A
P : PVC
H : C-PVC
(8) Seat material (11) Positioner control pattern (TAD)
E : EPDM
B : NBR
V : FKM
(11) Positioner control pattern (PSO / TAO)
(9) Size [mm]
ex. 25 A ® 025
(11) Positioner control pattern (PSC / TAC)
Threaded End Rc
Z - 9 5 T U
Z - 9 7 T P
Z - 9 7 T H
(2) (3) (4) (5) (6) (7) (8)
FR : Filter Regulator Unit
LB : Limit Switch Box
EP : Positioner
EX : Smart Positioner
ES : Smart Positioner
ER : Smart Positioner
A : SHUT by 4 mA « OPEN by 20 mA
B : SHUT by 20 mA « OPEN by 4 mA
C : OPEN by 20 mA « SHUT by 4 mA (Airless SHUT)
D : OPEN by 4 mA « SHUT by 20 mA (Airless SHUT)
E : SHUT by 4 mA « OPEN by 20 mA (Airless OPEN)
T : SHUT by 20 mA « OPEN by 4 mA (Airless OPEN)
1/10
OSPZX225-EN
Socket End
- - -
- - -
- - -
(9) (10) (11)
SP-1474
