GENERAL
A plastic ball valve and high-power electric actuator.
Various connections can be selected.
(J10K Flanged-end / Threaded End Rc / Socket)
Actuator
AE1 : For AC power
AE2 : For AC / DC power
Valve
Various materials can be selected.
PA type 2-way ball valve
PL type 3-way ball valve
PRODUCT CODE
PA / PL type
J10K Flanged-end
PA / PL type
Threaded End Rc
PA / PL type
Socket
(1) Actuator
AE1
AE2
(2) Valve
PA
PL
(3) Voltage
1 : 100 / 110 V AC
2 : 200 / 220 V AC
0 : 24 V DC
Instruction manual
Electric Actuated Ball Valve
(1)
(4) Sizing code
0 : Standard
1 : Light
2 : Heavy
(5) Connection
1 : J10K Flanged-end
5 : Threaded End Rc
7 : Socket
PA PL
1 P P
1 H H
1 R R
1 Q Q
5 P P
5 H H
5 R R
5 Q Q
7 P P
7 H H
7 Q Q
(2) (3) (4) (5) (6) (7) (8)
(6) (7) Body / Ball
P : PVC
H : C-PVC
R : PVDF
Q : PP
(8) Stem seal
E : EPDM
V : FKM
(9) Size [mm]
ex. 25 A ® 025
1/13
OSBPA225-EN
PA
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
(9)
(10)
(10) Option
L0 : Auxiliary limit switch
L2 : Auxiliary limit switch
SP-1474
PL
Advertisement
Table of Contents
Related Manuals for VPro PA
Summary of Contents for VPro PA
- Page 1 Actuator AE1 : For AC power AE2 : For AC / DC power Valve Various materials can be selected. PA type 2-way ball valve PL type 3-way ball valve PRODUCT CODE PA / PL type J10K Flanged-end 1 P P...
- Page 2 PVDF Seat PTFE PTFE Stem seal O-ring EPDM EPDM PRESSURE & TEMPERATURE RATING (PA) Body material: PVC / C-PVC Body material: PVDF / PP PRESSURE & TEMPERATURE RATING (PL) Body material: PVC / C-PVC Body material: PVDF / PP FLOW PATHS (Position...
- Page 3 OSBPA225-EN ELECTRIC ACTUATOR SPECIFICATIONS 3 way valve: SHUT / Position , OPEN / Position type Actuator type AE1-120- AE1-300- AE1-600- AE1-02K- AE1-06K- ( :Voltage code) Voltage 100 / 110 V AC ±10 % 50/60 Hz (Code: 1) 200 / 220 V AC ±10 % 50/60 Hz (Code: 2) Rated torque [N m] 12...
- Page 4 OSBPA225-EN ELECTRIC ACTUATOR SPECIFICATIONS 3 way valve: SHUT / Position , OPEN / Position type Actuator type AE2-120- AE2-300- AE2-600- AE2-02K- AE2-06K- AE2-120-0 ( :Voltage code) Voltage 100 / 110 V AC ±10 % 50/60 Hz (Code: 1) 24 V DC (Code: 0) 200 / 220 V AC ±10 % 50/60 Hz (Code: 2)
-
Page 5: Optional Parts
OSBPA225-EN ELECTRIC ACTUATOR SPECIFICATIONS 3 way valve: SHUT / Position , OPEN / Position OPTIONAL PARTS Specifications Code No. AE1 AE2 Remarks Auxiliary limit switch Select limit switch depending on the load For standard signal For micro load signal *Auxiliary limit switch: Please refer to the specifications. WIRING (OPTION) L0 / L2 Auxiliary limit switch... -
Page 6: Unpacking And Storage
OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS UNPACKING AND STORAGE WARNING WARNING • Using a positive-pressure gas with our plastic piping When suspending and supporting a valve, take care may pose a dangerous condition due to the repellent and do not stand under a suspended valve. -
Page 7: Flanged End
OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS HOW TO INSTALL A PLASTIC BALL VALVE FLANGED END WARNING CAUTION • When suspending and supporting a valve, take care • Do not use the valve to fluid containing slurry. and do not stand under a suspended valve. (The valve will not operate properly.) •... - Page 8 OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS When the Union Nut is Loosened or Removed Threaded End CAUTION If the union nut has been removed from the body • Avoid excessive tightening. (or loosened), install it in the following manner. (The valve can be damaged.) •...
- Page 9 OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS Socket End (PVC / C-PVC) 6) After applying adhesive, insert the pipe quickly WARNING to the Body Cap and leave it alone for at least • When using an adhesive, ventilate the space 60 seconds. sufficiently, prohibit the use of a fire in the vicinity, Do not under any circumstances try to and do not inhale adhesive vapors directly.
- Page 10 OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS How to install the support for the valve (PA type) HORIZONTAL PIPING (FLANGE TYPE) CAUTION If you do not use a bottom stand (ensat) and you are • Do not allow the piping around the pump to cause installing a support, you may need to install a significant vibration to the valve.
-
Page 11: Installation
OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS INSTALLATION PREVENT DEW CONDENSATION PRECAUTIONS • When installing the cover after wiring, perform the Before installing, clean pipe and valve ends. bolt by the temporary tightening procedure and the Make sure they are free of dirt, dust and etc. permanent tightening procedure to tightly and INSTALLATION NOTES securely tighten the rubber packing so that water... -
Page 12: Manual Operation
OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS MANUAL OPERATION PRECAUTIONS • Be sure to turn off the power before manual operation. • Operate manually with reference to the opening degree label. Do not turn beyond the fully open / fully closed position. Operation failure may occur during automatic operation. -
Page 13: Troubleshooting
OSBPA225-EN INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS TROUBLE SHOOTING Problem Cause Solution Problem Cause Solution Actuator Faulty wiring. Correct the wiring. Stop in the • Biting of Remove a foreign does not mid position. valve seat. object. move. • The scale has adhered No voltage is Check the voltage.
