- Page 1 4KEX100-L 100m HDBasT Extender User Manual...
-
Page 2: Trademarks Notice
AV Access Technology Limited assumes no responsibility for any inaccuracies that may be contained in this document. AV Access Technology Limited also makes no commitment to update or to keep current the information contained in this document. -
Page 3: Important Safety Instructions
Important Safety Instructions Do not expose this device to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the device. Do not install or place this unit in a bookcase, built-in cabinet, or in another ... -
Page 4: Table Of Contents
Table of Contents Introduction ......................2 Overview ..........................2 Features ............................ 2 Package Contents ........................3 Panel ............................4 Front Panel........................4 Rear Panel ........................4 Installation and Application................. 7 Brackets Installation ......................7 IR Cable Operation ........................ 7 Cable Type ........................7 Using the IR Emitter ..................... -
Page 5: Introduction
Introduction Overview 4KEX100-L is a pair of slim HDMI extenders, and it is designed to extend 4K HDMI signals up to 70m/230ft via a single Cat 5e/6 cable and 100m/330ft via a single Cat 6a/7 cable. The Transmitter and Receiver just need a single power supply to power both devices via its bi-directional PoE function. -
Page 6: Package Contents
Introduction Support RS232 ports for firmware upgrading or signal controlling. Support Ethernet pass-through. Note: The actual signal transmission distance can vary and depends on signal resolution, cable quality, graphics card, and display used in the system. Package Contents Before you start the installation of the product, please check the package contents: Transmitter x 1... -
Page 7: Panel
Introduction Panel Front Panel Transmitter/Receiver Name Description ON: The device is powered on. Power LED OFF: The device is powered off. Status LED Blinking: Transmitter/Receiver works properly. Off: Transmitter/Receiver does not work properly. On: Transmitter and Receiver are linked. Link LED Blinking: Connection exception. - Page 8 Introduction Name Description DC 18V Connect to the power adapter provided. Twisted Pair Connect to the Twisted Pair port of the receiver. IR In Connect to the IR receiver provided. IR Out Connect to the IR emitter provided. Connect to a RS232 device for pass-through or connect RS232 to a PC for firmware upgrading.
- Page 9 Introduction Name Description to a PC for firmware upgrading. HDMI Out Connect to an HDMI display. Connect to a network access point or a network Ethernet terminal device. Normal: RS232 signals can be transmitted Receiver cannot be updated. Mode Update: RS232 signals cannot be transmitted...
-
Page 10: Installation And Application
Installation and Application Installation and Application Brackets Installation Note: Before installation, please ensure 4KEX40-L is disconnected from the power source. Steps to install the device in a suitable location Attach the installation bracket to the enclosure using the screws that were provided in the package separately. -
Page 11: Using The Ir Emitter
Installation and Application Broadband IR Receiver (30-50 KHz): connect to the "IR In" port of the device. Using the IR Emitter Insert the IR emitter plug into the “IR Out” jack located on the transmitter or receiver. Example 1: Attach the IR emitter head directly with the adhesive tape provided near the IR receiver window (e.g. - Page 12 Apple TV (3rd/4th generation) Amazon Fire TV IR Receiver TIVO BOLT Note: Products from AV Access do not support Bluetooth control, the introduction above applies to device with IR control capability only. Here is a list about different devices' control method. www.avaccess.com...
- Page 13 Installation and Application Device Control Method NVDIA 2571 Player Bluetooth/USB Amazon Fire TV with UHD HDR Bluetooth Amazon Fire TV ROKU Ultra Player Bluetooth Apple TV 3rd Apple TV 4th Apple 4K TV 5th Bluetooth Xbox one S Bluetooth/USB Xbox one X Bluetooth/USB TIVO BOLT NINTENDO SWITCH HAC-001...
-
Page 14: Application
Installation and Application Application Power Supply Blu-ray Player Connect power Connect the IR Connect an HDMI adapter provided emitter provided Source (Such as Blu-Ray to the transmitter to IR Out port Player) to HDMI In (or receiver). of the transmitter port of the transmitter. -
Page 15: Specifications
Specifications Specifications Technical Video Signal Type HDMI 1.4 with 4K2K 4K@60 4:2:0 Input/Output Resolution Support /1080P/1080i/720P/576P/480P/576i/480i Supports multichannel audio up to PCM Audio Format Supported 7.1, Dolby True HD, DTS HD Master Audio, Dolby Atmos and DTS:X Max Data Rate 6.75 Gbps General Operating Temperature... -
Page 16: Rs232 Operation
RS232 Operation RS232 Operation You can use a RS232 port on Transmitter and Receiver to connect to a computer to update firmware or connect a RS232 device to communicate with another RS232 device on the other extender's side via a Cat 5e/6/6a/7 cable. Scenario 1 Slide Mode switch of TX/RX to “Update”... - Page 17 RS232 Operation Scenario 2 Slide “Mode” switches of TX/RX to “Normal” side, connect RS232 devices to RS232 ports of TX/RX. RS232 Device RS232 Transmitte r Cat x Receive r RS232 RS232 Device www.avaccess.com services@avaccess.com...
-
Page 18: Trouble Shooting
Trouble Shooting Trouble Shooting Steps of Regular Troubleshooting Routine Power: Please make sure all devices are powered on. (source, extender, display devices) Indicator: Please make sure LED indicators of transmitter and receiver are normal according to user manual. Devices: Please make sure picture can be shown normally when connecting source to display devices directly. -
Page 19: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 20 AV Access Technology Limited V1.0.0...
