Aputure Light Octadome 120 Product Manual

Foreword

Thank you for purchasing Light Octadome 120.
Light Octadome 120 is designed for LS 120d II,LS 300d II,LS 300X，
LS 600d Pro,Amaran 60,Amaran 100 and Amaran 200 series.
And also compatible with other Bowens Mount LED video light.

IMPORTANT SAFETY INSTRUCTIONS

When using this unit, basic safety precautions should always be
followed, including the following:
1. Read and understand all instructions before using.
2. Close supervision is necessary when any fixture is used by or
near children. Do not leave the fixture unattended while in use.
3. Care must be taken as burns can occur from touching hot surfaces.
4. Care must be taken when touching, installing or disassembling
the elastic support rod.
5. Let the fixture cool completely before storing.
6. To reduce the risk of injury, please install or disassemble the fixture
properly.
7.The use of an accessory attachment not recommended by the
manufacturer may increase the risk of fire, electric shock, or injury
to any persons operating the fixture.
8. Please do not place the fixture near any liquids or other
flammable objects.
9. Only use a dry microfiber cloth to clean the product.
10.This product is certified by RoHS. Please operate the product
in full compliance with the operation standards.
Product Manual
Please note that this warranty does not apply to repairs arising
from malfunctions, although you may request such repairs on a
English
chargeable basis.
11. The instructions and information in this manual are based on

Installations

thorough, controlled company testing procedures. Further notice
According to the diagonal installation method, insert the eight
will not be given if the design or specifications change.
support rods, then lock the chuck, and fit the velcro on the softbox,
then install the softbox on the lamp.
SAVE THESE INSTRUCTIONS

Check list

When you unbox the product, please make sure all the items listed
below are included. Otherwise, please contact the seller immediately.
Light Octadome 120 softbox (1pc) Speed Ring Adapter (1pc)
Use Velcro to install the
Inside Fabric Diffusion Front Fabric Diffusion
(1pc 1.5 Stop Diffusion,
(1pc)
1pc 2.5 Stop Diffusion)
Fabric Light Control Grid Light Octadome 120
Carrying Bag (1pc)
（1pc）
Tips: The illustrations in the manual are only diagrams for reference. Due to the continuous
development of new versions of the product, if there are any differences between the product
and the user manual diagrams, please refer to the product itself.
Disassembly: Pull out eight steel rods diagonally and in the opposite
direction
1
2
1
Specifications
Item
φ120cm*53.5cm/φ47.24in*21.06in
softbox(built)
(Inside diameter 107cm/42.1in)
softbox(Collapsed)
76x15x3cm/30*5.9*1.18in
3
φ120cm/φ47.24in
Front Fabric Diffuser 1(1.5 stop)
(Inside diameter 107cm/42.1in)
φ120cm/φ47.24in
Front Fabric Diffuser 2(2.5 stop)
(Inside diameter 107cm/42.1in)
Inside Fabric Diffusion φ34cm/13.6in
Fabric Light Control Grid on the diffuser.
φ120*5.3cm/φ47.24*2.08in
Fabric Light Control Grid
(Inside diameter 107cm/42.1in)
Speed Ring Adapter Standard Bowens Mount
Trademarks
2
Bowens is a trademark registered by Bowens in China and other
countries.
1
Detailed product manual can be found on www.aputure.com.
2
Dimension
Net Weight
1705g
