- Page 1 4K@60HZ HDMI User's Manual EXTENDER POC Manuale d’istruzione Technical features P/N: IDATA EXT-410P 8058956621130 WWW.TECHLY.COM...
- Page 2 • Do not install the product at places subject to vibration, or oscillation • Do not modify and alter the product and any accessories! Do not use any damaged parts. WWW.TECHLY.COM...
- Page 3 INSTALLATION REQUIREMENTS DESCRIPTION REQUIREMENT Device with HDMI Signal source port (PC, DVD, NVR, HDMI cable ≤ 5m etc..) Cat6/6A/7, following Cable standard EIA/TIA Cat 6/6A/7 ≤ 60m 568B TV, projectors, etc Display device HDMI cable ≤ 5m with HDMI port WWW.TECHLY.COM...
- Page 4 HDMI Ca Transmitter Receiver Macbook D C 5V Connect with Cat6/6A/7 RJ45 signal input network cable Connect with HDMI display HDMI signal output device with HDMI cable HDMI Cable CAT6 60m HDMI Ca Transmitter Receiver Macbook D C 5V WWW.TECHLY.COM...
- Page 5 A: 1) Check if the lenght of the cables is within the specific range. 2) Reconnect the network cable or HDMI cables. Q: Why is the display color abnormal or no sound? A: 1) Check if the HDMI cables are connected well. 2) Reconnect the network cable. WWW.TECHLY.COM...
- Page 6 3840x2160@24/25/30/50/60Hz, Resolutions 4096x2160@24/25Hz, 1280x960, 1280x800, 1280x768, 1680x1050, 1920x1200, 1360x768, 1366x768, 1600x900, 1024x768, 800x600 Transmission Cat6/6A/7 ≤60m distance AUDIO SIGNAL Input interface 1 x HDMI Output interface 1 x HDMI HDMI output LPCM / DTS 5.1/ Dolby Digital 5.1 CH WWW.TECHLY.COM...
- Page 7 0-90% RH (no condensation) Housing Metal Weight Dimension 67.0 (L) x 40.0 (D) x 23.0 (H) mm ESD protection 1a Contact discharge level 2 (+/-4KV) 1b Air discharge level 3(+/-8KV) Protection Implementation of the standard: IEC61000-4-2 Lightning protection, Surge protection WWW.TECHLY.COM...
- Page 8 There is a separate collections system for these products in compliance with WEEE directive, otherwise contaminative and hazardous substances can pollute the environment. With the CE sign, Techly ensures that the product is ® conformed to the basic European standards and directives.
- Page 9 • Non installare il prodotto in luoghi soggetti a vibrazioni o oscillazioni. • Non modificare o alterare il prodotto e i suoi accessori! Non utilizzare parti danneggiate. • Mantenere sufficiente spazio attorno alla periferica per garantire una buona ventilazione, permettere una maggiore libertà di movimento ed evitare danni. WWW.TECHLY.COM...
- Page 10 Apparecchiatura Sorgente segnale con porta HDMI Cavo HDMI ≤ 5m (PC, DVD, NVR, ecc) Cat6/6A/7 che Cavo segue lo standard Cat 6/6A/7 ≤ 60m EIA/TIA 568B Dispositivo TV, proiettore, ecc Cavo HDMI ≤ 5m di visualizzazione con porta HDMI WWW.TECHLY.COM...
- Page 11 D C 5V Collegare con un cavo di rete Ingresso segnale RJ45 Cat6/6A/7 Collegare con un dispositivo Uscita segnale HDMI di visualizzazione HDMI tramite HDMI Cable CAT6 60m HDMI Ca un cavo HDMI Transmitter Receiver Macbook D C 5V WWW.TECHLY.COM...
- Page 12 2) Ricollegare il cavo di rete e i cavi HDMI. D: Perché lo schermo ha un colore anormale e non c'è alcun suono? R: 1) Verificare che i cavi HDMI siano collegati correttamente. 2) Ricollegare il cavo di rete. WWW.TECHLY.COM...
- Page 13 EDID passante HDMI 2.0 (Deep Color, 4K, HDR, Compatibilità YUV4:4:4) HDCP 2.2 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz, 3840x2160@24/25/30/50/60Hz, Risoluzioni 4096x2160@24/25Hz, 1280x960, 1280x800, 1280x768, 1680x1050, 1920x1200, 1360x768, 1366x768, 1600x900, 1024x768, 800x600 Distanza Cat6/6A/7 ≤60m di trasmissione WWW.TECHLY.COM...
- Page 14 Metallo Peso Dimensioni 67.0 (L) x 40.0 (P) x 23.0 (A) mm Protezione ESD 1a Contact discharge level 2 (+/-4KV) 1b Air discharge level 3(+/-8KV) Protezioni Implementation of the standard: IEC61000-4-2 Protezione contro i fulmini, protezione contro le sovratensioni WWW.TECHLY.COM...
- Page 15 Contattate le autorità locali competenti per ottenere informazioni in merito allo smaltimento corretto della presente apparecchiatura. Con il marchio CE, Techly garantisce che il prodotto è ® conforme alle norme e direttive europee richieste.
- Page 16 All rights reserved. All trademarks and trade names are those of their respective owners. TECHLY® - Viale Europa 33 - 33077 Sacile (PN) - Italy WWW.TECHLY.COM...
