SPECIFICATIONS (Continued)

Dimensions

QS200-10
QS200-10PW
1 INCH
4.25 in.
A. Length
(108mm)
5.38 in.
B. Height
(137mm)
C. Width
2.50 in.
(at widest
(64mm)
point)
4.47 in.
D. Depth
(114mm)
Figure 1
QS200-15
QS200-15PW
1-1/2 INCH
4.90 in.
(124mm)
5.63 in.
(143mm)
2.50 in.
(64mm)
4.47 in.
(114mm)
For 1 in., 1-1/2 in., & 2 in. Meters
For 3 in. & 4 in. Meters
7
QS200-20
QS200-30
QS200-20PW
QS200-30PW
2 INCH
3 INCH
5.56 in.
6.63 in.
(141mm)
(168mm)
6.12 in.
7.20 in.
(156mm)
(183mm)
2.88 in.
4.18 in.
(73mm)
(106mm)
4.94 in.
4.91 in.
(125mm)
(124mm)
QS200-40
QS200-40PW
4 INCH
7.38 in.
(187mm)
8.41 in.
(213mm)
5.23 in.
(133mm)
6.17 in.
(156mm)
SECT VIEW
(TEE ONLY)
SECT VIEW
(TEE ONLY)
