Getting Started - Flomec QS200 Product Owners Manual

BEFORE YOU BEGIN
Usage Requirements
•
•
•
•
Power Source Requirements
•
Tools and Materials Needed
•
•
•
•
UNPACKING
Contents: QS200-10, -15, -20, -30, -40 or
QS200-10PW, -15PW, -20PW, -30PW, -40PW Meters
NOTE: The "PW" suffix denotes an NSF certified meter
(1) QS200 Ultrasonic insert assembly
(1) PVC Pipe Tee (for 1 in., 1-1/2 in., 2 in., 3 in.,
or 4 in. diameter pipe)
(1) Quick Release Pin
Contents: QS200 Retrofit Insert (Not available as NSF certified)
(1) QS200 Ultrasonic insert assembly
(1) Set of two O-rings (round profile)
(2) K-factor Decals
Inspect
•
•
This meter is for use with water only.
This meter is not legal for trade applications.
This meter has a permanent factory setting for measuring water only.
Flow must go uphill through the meter, never downhill through the meter
to avoid air bubbles or air pockets captured in the Tee.
This meter requires DC power from a customer-provided controller in
order to provide flow information back to the controller.
Wire strippers, wire cutters, tape measure
PVC pipe fittings (as needed), PVC pipe primer, PVC pipe cement
Direct burial wire splices, valve box
#18 AWG wire cable (Direct Burial). (Controller manufacturer may
recommend thicker gauge wire for longer distances)
After unpacking the unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing or damaged
parts. Shipping damage claims must be filed with carrier.
See General Safety Instructions, and all Cautions, Warnings, and
Dangers as shown.
(1) Quick Release Pin
(1) Owner's Manual
4
(2) K-factor Decals
(1) Owner's Manual
