1.5.2- Addressable sensors ( A50 series )

1.5.2.1- Addresable Smoke-Heat and CO sensors with Isolator (A50SHCOI)

The A50 family of detectors are based on a new refined aesthetic that
integrates the latest electronic technology with new, more efficient
detection algorithms and a three-dimensional design that makes it more
robust against environmental dirt.
The A50 family allows multiple combinations between smoke and heat
detection, CO sensor and short-circuit isolator with UL certification.
The A50SHCOI model is a multi-sensor detector that has a short-
circuit isolator and three different types of sensors: A smoke sensor, a
heat sensor and a Carbon Monoxide (CO) sensor.
The use of the CO sensor is very valuable for the early detection of some types of fire, since the production of
this gas is very common, especially in the initial phases of a fire. Its integration with the smoke sensor results
in a compact detector that is very robust against false alarms.
To complete its features, a heat sensor with thermovelocimetric response is incorporated, reaching alarm status
with a static temperature of 60ºC in the case of slow fire developments.
Characteristics:
• Smoke, Heat and CO sensor.
• With short circuit isolator.
• Low profile, total height less than 55 mm (including low base).
• Also available with high base for 20 mm tube.
• Possibility of connection to a remote action indicator.
• Easy connection.
• Bicolor red and yellow LED.
• Indication, by means of the red LED, of the communication with the control panel (single flashing), as well
as of the alarm status (LED on).
• Indication, by means of the yellow led (single flash), of the activation of the short-circuit isolator or the lack
of communication with the control panel.
• Signaling of the dirty state of the sensor on the control panel display (the sensor allows to differentiate
between rapid signal increases due to alarm and small, slow and sustained increases due to the accumulation of
dust and dirt).
• Smoke and CO sensor processing algorithm that drastically reduces incidents due to false alarms.
• Easy installation of head and base, interchangeable throughout the A50 family, and made of white heat-
resistant ABS.
• UL certified according to Standard EN 54-5 class A2R, EN 54-7 and EN 54 17 with CE marking according
to the European Regulation on Construction Products (EU) No. 305/2011.
Power supply*
Standby consumption
Alarm consumption
Activity Indicators
Remote indicator output
Humidity
Temperature
Sensibility
IP
CO sensor lifespan
*NOTE: The Isolated series (A50SHCOI, A50SHI, A50HI, A50SI,) have polarity, as the A1 and A2
are positive and B is negative.
Digital fire detection control panel
COMPACT LYON PLUS
Technical Specifications - A50SHCOI
Bicolor LED, red and yellow
As required by EN 54-5, EN 54-7 y EN 54-17
FIRE PROTECTION MANUFACTURER
C / Compositor Wagner, 8 –P.I. Can Jardí 08191 - RUBÍ (Barcelona) ESPAÑA.
Tlf.: +34 935 862 690 – cofem@cofem.com
Sensor A50SHCOI
24 – 35 V no polarity *
0,3 mA
2 mA
Yes
20 – 95% HR
-10º + 50ºC
IP20
10 years
