This Administrator's Guide outlines the
key features of the SoundStation IP
3000 - 3Com NBX conference phone
and gives step-by-step instructions for
installation and configuration.
The SoundStation IP 3000 - 3Com NBX
has been specifically designed to work with
3Com NBX Call Processors. It will not
work with other VoIP protocols like H.323.

Typical Deployment

A typical deployment of the SoundStation
IP 3000 - 3Com NBX is shown in
Figure 1.
NBX Business Phone
This guide is for System Administrators
or Network Administrators who will
deploy and support this product in their
networks. To use this guide, you should
have a working knowledge of the 3Com
NBX system.
Figure 1 - Typical 3Com NBX Network Setup
SoundStation IP 3000 - 3Com NBX
Ethernet Switch
10M Shared 10M Shared
10/100M Switched 10/100M Switched
10M Link 10M Link
100M Link 100M Link
10/100M Switched 10/100M Switched
10M Link 10M Link
100M Link 100M Link
3C10200 NBX Gateway Chassis 3C10200 NBX Gateway Chassis

Introduction

Overview

3Com NBX Call Processor
Public
Switched
Telephone
Network
NBX 100
NBX 100
