Evaluation Board User Guide

BILL OF MATERIALS

Table 1.
Reference Designator
+5V, +15V, 3V3_USB, 1 5V_USB,
CE, 1 CLK, 1 DATA, 1 DVDD, 1 LE, 1
OPBIAS, T1, T2, RIG, VP
1 1 1 1
AGND, AGND1
C1
C2
C3
C4
C5, C8, C19, C21, C22, C28, C30, C32, C33
C6, C7, C20, C42, C44, C45, C46, C53, C54,
C55, C57, C58, C59, C60
C9
C10, C16, C18, C24, C38, C41, C52, C56
C11, C12, C49
C13, C48, C51
C14, C25, C29, C39
C15, C31, C47, C50
C17
C23, C37
C26, C27
C34
C35
C36
C40
C43 1
CPOUT, REFIN, VTUNE, VVCO
D1, D4
D2
D3
EXT_VCOOUT, VCO/2
GND
L1
L2
R1
R2
R3, R28, R38
R4
R5, R10, R21, R24, R26, R27, R29, R32, R35,
R37, R43, R46, R48, R52, R53, R56, R57,
R58, R60, R61, R68
R6, 1 R31, 1 R34, 1 R55, 1 R67 1
R7, R59, R62
R8, R23
R9, R18, R19
R11, R13, R14, R15, R17, R22,
1 1 1 1 1
R33, 1 R36, 1 R42, 1 R47, 1 R51, 1 R54,
R12
R16, R64, R65
R20
R39, R49, R50
R40
Part Description
1 AVDD, 1 Red test point
MUXOUT, 1
Black test point
Capacitor, 0603, 50 V, 680 pF, COG/NPO
Capacitor, 0603, X7R, 50 V, 68 nF
Capacitor, 0603, X7R, 50 V, 1.8 nF
Capacitor, 0603, X7R, 50 V, 2.7 nF
Capacitor, 0603, 1 μF, 10 V, X5R
X7R ceramic capacitor, 0402,16 V, 0.1 µF
X5R ceramic capacitor, 0402, 6.3 V, 0.22 µF
NP0 ceramic capacitor, 0402, 50 V, 10 pF
NP0 ceramic capacitor, 0603, 50 V, 1 nF
Tantalum capacitor (TAJ-A case), RTAJ_A, 6.3 V, 22 µF
COG ceramic capacitor, 0402, 50 V, 100 pF
Capacitor, X5R, 0805, 1.0 μF, 50 V
Capacitor, X5R, 0805, 10 V, 10 μF, 10%
X5R ceramic capacitor, 0402, 25 V, 0.1 µF
NPO SMD ceramic capacitor, 0603, 50 V, 10 pF
Multilayer ceramic capacitor, 0603, 10 pF
X5R ceramic capacitor, 0805, 6.3 V, 22 µF
Capacitor, CASE B, 100 μF, 6.3 V, RTAJ_B
Capacitor, 0402, 100 pF, 50 V, NP0
Capacitor, RTAJ_D
Conn jack end launch PC gold SMA
LED, green
Diode, standard, 1 A, 50 V
LED, red
High frequency SMA end launch connector—142-0761-801
Black 4 mm banana socket
Ferrite bead, 470 Ω at 100 MHz
Inductor, SMT Power EPL2014 Series, 4.7 µH
Resistor, 0603, 390 Ω
Resistor, 0603, 510 Ω
Resistor, 0603, 1 kΩ
Resistor, 0603, 5.1 kΩ
Resistor, 0603, 0 Ω
Resistor, 0402
Resistor, 0603, 10 kΩ
Resistor, 0603, 47 kΩ
Resistor, 0603, 330 Ω
R25, R30, Resistor, 0603
1 1 1
1 R63 1
Resistor, 0603, 49.9 Ω
Resistor, 0402, 0 Ω
Resistor, 0603, 10 Ω
Resistor, 0603, 2.2 kΩ
Resistor, 0603, 140 kΩ
