3.3 Connection diagram to the control box
10
E10W230WIFI(E10B230WIFI) - FULL MANUAL
E10W230WIFI
COM
N
L
N
L
SL1
1 - 8 Strefy
ECB08M230
listwa sterująca
N
SL1
Legend:
Temperature sensor
L, N - power supply
COM, NO - voltage-free output
S1, S2 - output for temperature sensor
SL1...SL8 - 230V control input in the control box
- fuse
S1
S2
NO
