- Page 1 ZigBee Smart Thermostat, Li-Ion battery EONEBATW EONEBATB FULL MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction ................................4 1.1 Product Compliance ..............................4 1.2 Safety Informations ..............................4 2. Product Overview ..............................5 2.1 Package content ..............................6 2.2 Proper thermostat location ...........................6 2.3 Wall mounting ..............................6 2.4 Description of thermostat terminals ........................7 3. Communication diagram ............................7 4. - Page 3 10.4 Settings (installer parameters) ..........................31 10.4.1 Key lock function..........................31 10.4.2 Setting PIN ............................32 10.4.3 Backlight brightness ..........................33 10.4.4 Max temp. limit ...........................34 10.4.5 Min temp. limit ............................34 10.4.6 Sensor Selection ..........................35 10.4.7 Temperature correction ........................37 10.4.8 Control type (algorithm)........................38 10.4.9 Comfort warm floor function ........................39 10.4.10 Valve protection ..........................40 10.4.11 Heating/Cooling mode selection ......................41 10.5 General orders ..............................42...
-
Page 4: Introduction
1. Introduction 1.1 Product Compliance This product complies with the essential requirements and other relevant provisions of Directives 2014/30EU, 2014/35/EU, 2014/53/EU and 2011/65/EU 1.2 Safety Informations • Before starting installation work and before using the product, read the entire manual. •... -
Page 5: Product Overview
Product features: • Communication using ZigBee 3.0 standard • Very easy to operate • A multitude of functions accessible through the ENGO Controls / Tuya Smart application • Option to connect an additional NTC sensor • Adjustable display backlight intensity •... -
Page 6: Package Content
2.1 Package content 1) EONEBAT thermostat 2) Wall mounting plate 3) Self-adhesive mounting tape 4) Quick Guide 5) Mounting screws EONE230W (white) or Wall mounting plate Self-adhesive Quick Guide Mounting screws EONE230B (black) thermostat mounting tape (white or black) Protective film with QR code for product page https://products.engocontrols.com/ is attached to thermostat 2.2 Proper thermostat location Uwaga: The recommended height for mounting the thermostat is approx. -
Page 7: Description Of Thermostat Terminals
2.4 Description of thermostat terminals Legend: Battery powered ZigBee 3.0 EONEBATW/B Temperature sensor S1, S2 Thermostat input for ext. temperature sensor Li-lon Connection with ZigBee 3.0 network 3.7V 3. Communication diagram Application Router Wi-Fi 2.4GHz Cloud ZigBee 3.0 Gateway EGATEZB*... -
Page 8: About Zigbee Network
4. About ZigBee network 4.1 ZigBee network creation and operation ZigBee - is a wireless network based on IEEE 802.15.4 standard and it’s communication takes place in the 2.4 GHz band. The network is based on a mesh topology, which allows for a very large range and high reliability. The maximum range of direct communication between two network nodes (devices) is about 100m in open space. -
Page 9: About Engo
It is similarly simple to solve the problem of turning off the light in the bedroom - if the bedside lamp is turned on, it can be set to turn off the light in the bedroom. Compatibility of devices in the ENGO Smart application: ENGO ZigBee ENGO Wi-Fi EONEBATW/EONEBATB EGATEZB EDOORZB E901WIFI E10W230WIFI/E10B230WIFI... -
Page 10: First Power On
6. First power on The thermostat is battery-powered. To turn it on, follow the instructions below. 3 sec. To power on the thermostat hold button ...the display will show all the icons... for 3 seconds..the main screen is appeared. EONEBAT FULL MANUAL... -
Page 11: Lcd Icon Descrption
6.1 LCD icon descrption Humidity Display Current Temperature / Setpoint Temperature Clock Temperature unit Heating indicator (icon is animating when there is heating demand) Cooling indicator (icon is animating when there is cooling demand) Schedule mode icon Temporary override mode Additional temperature sensor Key lock function Holiday mode... -
Page 12: Engo Smart App Installation
7. ENGO Smart app installation DOWNLOAD THE ENGO SMART APP: FOR A MOBILE DEVICE WITH ANDROID: FOR MOBILE DEVICE WITH IOS SYSTEM: Method 1: Scan the QR code with the device’s scanner, Method 1: Scan the QR code and follow the directions to get to download and install the app. -
Page 13: Account Registration
7.1 Account registration REGISTER THE NEW ACCOUNT: To register a new account, please follow the steps below: Click „Register” to create Enter your e-mail address to which new account. the verification code will be sent. Enter the verification code received Then set the password for in the email. -
Page 14: Password Reset
7.2 Password reset FORGOTTEN PASSWORD: If you have forgotten your password, you can log in as below: Click on „I forgot my password.” Enter the e-mail address used during account registration. Click to receive the verification code Enter the verification code received in the email. to the email address you entered. -
Page 15: Guidelines For Installing Devices In A Wifi Network
7.3 Guidelines for installing devices in a WiFi network • Make sure that the Wi-Fi network where you want to install the app broadcasts in the 2.4 GHz frequency. • We recommend turning off mobile internet (cellular data) on your phone during configuration. •... -
Page 16: Installation Of The Zigbee Thermostat In The App - Online
8. Installation of the ZigBee thermostat in the app - ONLINE 5 sec. 5 sec. Make sure that gateway has been On the EONE thermostat, hold buttons simultaneously added to the application. for 5 seconds until „PA” appears on the display. The thermostat will enter pairing mode. - Page 17 Wait for „End”. When the ZigBee network gateway has Name the device and click „Done”. correctly searches for the thermostat, click the button „Add.” On the thermostat screen appeared an icon globe indicating that it has been added to the ZigBee network. The thermostat has been installed and displays the main interface.
-
Page 18: Engo Binding
9. ENGO Binding The ENGO ZigBee series of devices - as the only one working on the basis of the TUYA platform - offers the so-called ENGO binding function, which allows direct binding of EONE thermostat with receivers (ECB62ZB control box, EMODZB module, EREL1ZB12A relay) using EGATEZB gateway. This makes it possible to bind devices without creating automation in the mobile application. -
Page 19: Linking Thermostat To The Control Module Emodzb
9.2 Linking thermostat to the control module EMODZB Make sure that the module and thermostat are in the same ZigBee network (they are added to the same gateway EGATEZB). 5 sec. 5 sec. To properly bind thermostat with the module On the EONE thermostat, Release the keys, binding first click quickly the button on the device... -
Page 20: Linking Thermostat To The Relay Erel1Zb12A
9.3 Linking thermostat to the relay EREL1ZB12A Make sure that the relay and thermostat are in the same ZigBee network (they are added to the same gateway EGATEZB). 5 sec. 5 sec. To properly bind thermostat with the relay Release the keys, binding function On the EONE thermostat, hold and buttons first click quickly the button on the device (process of linking thermostat) is active. -
Page 21: Thermostat Opperation In The App - Online
10. Thermostat opperation in the app - ONLINE 10.1 General information In this chapter, you can learn how to use the Engo One thermostat in connection with the ENGO Smart app. To be able to control the thermostat via the Internet, you will need an Internet connection and the ENGO Smart app. Controlling the thermostat via the app from a mobile device (IOS, Android) gives you a lot of freedom and the ability to remotely manage the temperature from anywhere. -
Page 22: Control
10.3 Control 10.3.1 Setpoint temperature change Changing the temperature setpoint is done by moving the cursor left / right in the app. On the screen, the actual temperature setpoint is represented by the number displayed in larger font. Enter the thermostat interface. Make a new temperature setting by The thermostat started sending moving the slider along the bar. -
Page 23: Power" Function
10.3.2 „Power” function In this option, the user can turn ON / OFF the thermostat from the app without the need to interfere with the power wire. To do so, please follow the steps below: Enter the thermostat interface. Select the „Control” option. You can turn the thermostat on / off by using „Power”... -
Page 24: Manual Mode
10.3.3 Manual mode In the manual mode, the thermostat will maintain the temperature setpoint until the user changes it again via the app or thermostat, or selects a new operating mode in the app. To set the manual mode, follow the steps below: Enter the thermostat interface. -
Page 25: Schedule Mode
10.3.4 Schedule mode The ZigBee thermostat allows you to set schedules. When creating a schedule, the time of its commencement along with the set temperature is given. A maximum of 6 switching points can be set for each day of the week. To activate the schedule, press the schedule icon in the „Work modes”... - Page 26 TO PROGRAM A SCHEDULE IN THE APP: Enter the thermostat interface. Select the „Control” option. Select schedule mode. Enter the schedule settings. Select one of the six switch points to Select the start time of edit (the editing order is optional). the switch point.
- Page 27 Next click „Confirm”. After all, you will see ready program Set the temperature which applys in the schedule. Select another when the program starts. program and follow steps 5 to 8. COPYING DAYS The ENGO Smart app allows you to copy the settings of a selected day in the schedule to another. Thanks to this, you do not have to set the next day for the second time if you want to have exactly the same settings in it.
-
Page 28: Holiday Mode
10.3.5 Holiday mode In the holiday mode, you can program the temperature that will be maintained for a selected number of days (e.g. during a home absence). TO SET THE HOLIDAY MODE: Enter the thermostat interface. Select the „Control” option. Select Holiday mode. -
Page 29: Frost Mode
10.3.6 FROST mode In the FROST mode, the preset temperature in the thermostat is kept as a constant, selectable value from the range of 5°C - 17°C.. When the anti- freeze (FROST) mode is active, a snowflake icon is displayed on the thermostat. When the ambient temperature drops below selected setpoint temperature, the thermostat will start sending the heating signal. -
Page 30: Diagrams
10.3.7 Diagrams The ENGO Smart app offers room temperature history graphs and the heating time coefficient for the selected day. They allow you to better plan the operation of the thermostat, e.g. using the schedule mode based on the recorded data, which will make the operation even more economical. Enter the thermostat interface. -
Page 31: Settings (Installer Parameters)
10.4 Settings (installer parameters) 10.4.1 Key lock function The app allows you to lock the buttons on the device. Just change the position of the slider on the screen. When the dot is green and on the right, then thermostat keys are locked. To unlock, press the slider again so that it is unlit and to the left. Then the buttons on the thermostat are unlocked. You can also lock/unlock from the thermostat using the keys UP and OK. -
Page 32: Setting Pin
10.4.2 Setting PIN From the app, the user has the option of enabling or disabling the PIN lock for the installer settings and for unlocking the thermostat buttons.. ATTENTION!!! PIN code cannot be set within the mobile app. This has to be done within thermostat installer parameters. 1. -
Page 33: Backlight Brightness
10.4.3 Backlight brightness The user can change the brightness of the thermostat display. Move the slider to the appropriate direction as in the steps below: Enter the thermostat interface. Select „Settings”. Use the slider to set the brightness of the display. When the slider is moved (see previous step), the thermostat display automatically changes its brightness. -
Page 34: Max Temp. Limit
10.4.4 Max temp. limit This parameter allows you to set the maximum temperature setpoint in the thermostat. Take a look at the steps below: Enter the thermostat interface. Select „Settings”. Use the slider to change the value for the maximum temperature set point (from 5°C to 45°C). -
Page 35: Sensor Selection
10.4.6 Sensor Selection Internal temperature sensor (IN) - By default, the thermostat measures the temperature with the thermostat’s internal built-in temperature sensor and input S1/S2 is inactive Enter the thermostat interface. Select „Settings”. Select internal (IN) sensor. Internal sensor + floor temperature sensor - if you connect an additional floor sensor to terminals S1/S2 of the thermostat, both sensors are active (internal and external). - Page 36 External temperature sensor (as an air sensor) - if an external sensor is connected to the S1/S2 terminals and selected external sensor, the thermostat will display the temperature from this sensor ignoring the internal sensor. The external temperature sensor can be used in case where the thermostat need to be in other place than controlled room.
-
Page 37: Temperature Correction
10.4.7 Temperature correction This function allows you to adjust the room temperature by ± 3.5°C in steps of 0.5°C. Take a look at the steps below: Enter the thermostat interface. Select „Settings”. Use the slider to select the correction value for the current temperature. EONEBAT FULL MANUAL... -
Page 38: Control Type (Algorithm)
10.4.8 Control type (algorithm) HYSTERESIS ALGORITHM uses a temperature difference (against setpoint temperature) to switch heating device ON and OFF. If thermostat works over hysteresis and it is used in a slow response system (e.g. underfloor heating), cycles of underheating and overheating cannot be avoided. It is difficult to maintain a constant temperature in the room because the thermostat is activated when the temperature drops below the setpoint temperature. -
Page 39: Comfort Warm Floor Function
10.4.9 Comfort warm floor function This function helps to keep the floor warm, even if the room is warm enough and there is no need to turn on the heating. User can select 5 levels of warm floor feature. For small rooms with short loops that can be heated quickly, level 1 is dedicated. For large rooms with long loops level 5 is dedicated. -
Page 40: Valve Protection
10.4.10 Valve protection Valve protection function is intended to protect thermostatic valves against getting stuck or jamming (e.g. in summer time when heating system is disabled). If thermostat doesn’t send a signal for heating for a period of 7 days, then heating is turned on for a very short period of time just to move the actuators Enter the thermostat interface. -
Page 41: Heating/Cooling Mode Selection
10.4.11 Heating/Cooling mode selection This function allows you to select the operating mode of the thermostat: a) operating the heating system (factory setting), Enter the thermostat interface. Select „Settings”. Select „Heating”. b) operation of cooling system. Enter the thermostat interface. Select „Settings”. -
Page 42: General Orders
10.5 General orders 10.5.1 Change the name, icon and location of the thermostat Name the thermostat, edit its icon or define it’s location (room). Enter the thermostat interface. Click the pencil icon in the top Tap the name of the thermostat. right corner. - Page 43 Write a name and click save. Determine the location of Choose a place and click „Save” the thermostat. in the top right corner. EONEBAT FULL MANUAL...
-
Page 44: Device Information
10.5.2 Device information The user will find here detailed information about the device, eg. Virtual ID, device IP, MAC address, the time zone in which the device is located and signal strength. Check the steps below: Enter the thermostat interface. Click the pencil icon in the top right corner. -
Page 45: Tap-To-Run And Automation
10.5.3 Tap-To-Run and Automation The „Tap-To-Run” and „Automation” rules are a preconfigured set of actions defined by an easy-to-use interface. Besides the obvious tasks that can be programmed to keep the system running automatically. In addition, there are also functions that improve the visual effect and the convenience of use. - Page 46 Use the slider to set the value of room Go „Next”. Add an action to perform. temperature, below which you will receive a notification of low room temperature. Select „Send notification”. Click „Message center”. Go „Next”. EONEBAT FULL MANUAL...
- Page 47 Click „Save”. Click „Yes” The rule was written when temperature in the room drops below the value, the application will send notification about this event. EONEBAT FULL MANUAL...
-
Page 48: Sharing Devices/Home
10.5.4 Sharing devices/home The ENGO Smart app offers the possibility of sharing the selected device with other users (assigned to the home). You can also assign a user the role of administrator/standard user. To do this, follow the steps below: Click the home name. - Page 49 The invited user must confirm their When the user accepts the invita- To go to edit click desire to join home. tion, will be visible in the on the username. list of home members. We can edit the name of the user A member of the home can be given and permissions by clicking administrator permission or...
-
Page 50: Create Group
10.5.5 Create group Simultaneous control will be available after creating a new group and assigning the selected thermostats to this group. Then, a virtual master thermostat appears on the desktop, which allows you to overwrite all parameters in the grouped thermostats. For example: If you set the virtual thermostat to manual mode, then each thermostat in this group will switch to manual mode. - Page 51 The main group management inter- The group will also face will be displayed from where automatically appear on you can set temperature or change the main screen of the app. operation modes / settings. EONEBAT FULL MANUAL...
-
Page 52: Faq & Feedback
10.5.6 FAQ & Feedback Find the answer to the problem in the FAQ option and opinions (the most common problems and questions) by searching for a specific key word. If you did not find the answer, please contact technical support. Enter the thermostat interface. -
Page 53: Add To Home Screen
10.5.7 Add to home screen If you are tired of constantly opening the app to enter the thermostat settings, or if you want to set a new temperature quickly - pin the thermostat to the main desktop of your smartphone. See steps below: Enter the thermostat interface. -
Page 54: Device Update
10.5.8 Device update It allows you to update the device software to the latest version. You can start the update manually or choose the automatic update option. Enter the thermostat interface. Click the pencil icon in the top Select „Check for available right corner. -
Page 55: Alarms / Push Notifications / Emergency States
11. Alarms / Push notifications / Emergency states E1 – Short-circuit in the circuit of the external temperature sensor plugged into the S1/S2 contacts. • If the sensor is connected to the S1/S2 input, check the wiring. • Check for insulation damage (short circuit) in the wiring of the sensor wiring. - Page 56 Alerts. To access notifications follow these steps: engo@gmail.com Enter „Me” menu. Select „Message Center”. Move sequentially between the tabs: Alarm, Devices and Notifications in order to find a message or notification regar- ding to the thernostat. EONEBAT FULL MANUAL...
-
Page 57: Remove Device
12. Remove device To remove the EONE thermostat from your account, follow these steps: To remove the EONE thermostat from your account, follow these steps: Click and hold the thermostat icon. Click the pencil icon in the top Select „Remove Device”. right corner. -
Page 58: Installation Of The Zigbee Thermostat In The App - Offline
13. Installation of the ZigBee thermostat in the app - OFFLINE 13.1 Adding thermostat to the ZigBee network 5 sec. 5 sec. On the EONE thermostat, hold buttons simultaneously for 5 seconds until „PA” appears on the display. The thermostat will enter pairing mode and count backwards (180s). On the EGATEZB gateway, press the RESET After the pairing is completed, the thermostat button. -
Page 59: Linking Thermostat To The Wireless Control Box Ecb62Zb
The ENGO ZigBee series of devices - as the only one working on the basis of the TUYA platform - offers the so-called ENGO binding function, which allows direct binding of EONE thermostat with receivers (ECB62ZB strip, EMODZB module, EREL1ZB12A relay) using EGATEZB gateway. This makes it possible to bind devices without creating automation in the mobile application. -
Page 60: Linking Thermostat To The Control Module Emodzb
13.3 Linking thermostat to the control module EMODZB Make sure that the module and thermostat are in the same ZigBee network (they are added to the same gateway EGATEZB). 5 sec. 5 sec. To properly bind thermostat with the module On the EONE thermostat, Release the keys, binding first click quickly the button on the device... -
Page 61: Linking Thermostat To The Relay Erel1Zb12A
13.4 Linking thermostat to the relay EREL1ZB12A Make sure that the relay and thermostat are in the same ZigBee network (they are added to the same gateway EGATEZB). 5 sec. 5 sec. To properly bind thermostat with the relay Release the keys, binding function On the EONE thermostat, hold and buttons first click quickly the button on the device (process of linking thermostat) is active. -
Page 62: Offline Installer Parameters
14. Offline installer parameters To enter the installer mode, hold down the button for 3 seconds. Navigate between parameters using the buttons . Enter a parameter using the button. Edit a parameter using the buttons. Confirm the new parameter value 3 sec. -
Page 63: Factory Reset
Do not spray cleaner directly onto the device. After washing the surface, you can gently polish it with a soft, dry cloth. There are no user serviceable / replaceable parts inside. Service or repair may be performed only by an authorized ENGO Controls service. -
Page 64: Technical Informations
17. Technical Informations Built-in Li-Ion 3,7V Battery Power supply Charging connector USB type C, 5V DC Temperature range 5,0°C - 45,0°C Display temperature accuracy 0,5°C Control algorithm TPI or Histeresis (from ±0,1°C to ±2°C) Communication ZigBee 3.0 2,4GHz S1/S2 multifunctional input Floor temp sensor, external air sensor, occupancy sensor IP protection class IP30... -
Page 65: Warranty
18. Warranty ENGO CONTROLS warrants this product to be free from any defects in material or workmanship and to perform as specified for a period of five years from the date of installation. ENGO Controls reserves the sole responsibility for breach of this warranty by repairing or replacing the defective product. - Page 67 Ver. 1 Date of issue: VII 2023 Producer: Engo Controls S.C. 43-200 Pszczyna 3E Górnośląska St. Poland Distributor: QL Controls Sp z o.o. Sp. k. 43-262 Kobielice 4 Rolna St. Poland www.engocontrols.com...
