9.9

DisplayPort

Table 14

DisplayPort Signal Descriptions

Signal

Pin # Description

DP_LANE3+

131

DisplayPort differential pair lines lane 3 (Shared with

DP_LANE3-

133

TMDS_CLK+ and TMDS_CLK-)

DP_LANE2+

143

DisplayPort differential pair lines lane 2 (Shared with

DP_LANE2-

145

TMDS_LANE0+ and TMDS_LANE0-)

DP_LANE1+

137

DisplayPort differential pair lines lane 1 (Shared with

DP_LANE1-

139

TMDS_LANE1+ and TMDS_LANE1-)

DP_LANE0+

149

DisplayPort differential pair lines lane 0 (Shared with

DP_LANE0-

151

TMDS_LANE2+ and TMDS_LANE2-)

DP_AUX+

138

Auxiliary channel used for link management and

DP_AUX-

140

device control. Differential pair lines.

DP_HDMI_

154

Hot plug detection signal that serves as an interrupt

HPD#

request.

Note

The conga-QMX6 does not offer DisplayPort interface because the interface is not supported by the Freescale

9.10

HDMI

Table 15

HDMI Signal Descriptions

Signal

Pin # Description

TMDS_CLK+

131

TMDS_CLK-

133

TMDS_LANE0+

143

TMDS_LANE0-

145

TMDS_LANE1+

137

TMDS_LANE1-

139

TMDS_LANE2+

149

TMDS_LANE2-

151

HDMI_CTRL_CLK

152

HDMI_CTRL_DAT

150

DP_HDMI_HPD#

153

Note

On the conga-QMX6, only the HDMI interface supports the Transition Minimized Differential Signaling (TMDS)

TMDS differential pair clock lines.

TMDS differential pair lines lane 0.

TMDS differential pair lines lane 1.

TMDS differential pair lines lane 2.

DDC based control signal (clock) for HDMI device.

DDC based control signal (data) for HDMI device.

Hot plug detection signal that serves as an interrupt request. I 3.3V

I/O

PU/PD Comment

O PCIE
