2.2

Supported Operating Systems

The conga-QMX6 supports the following operating systems.

• Microsoft

Windows

• Android

• Linux

2.3

• 70.0 mm x 70.0 mm @ (2 ¾" x 2 ¾")

• The Qseven™ module, including the heatspreader plate, PCB thickness and bottom components, is up to approximately 12mm thick.

Embedded Compact 7

2.00

6.00

Dimension is dependent

1.20 ±0.1

on connector height used

Rear View of Qseven Module

Heatspeader

Qseven Module PCB

8.00

All measurements are in millimeters

All dimensions without tolerance ±0.2mm

Carrier Board PCB

QMX6m03

Dimension is dependent

on connector height used

14/63
