Revision History
Revision Date (yyyy.mm.dd) Author Changes
0.1 2013.03.28 AEM
0.2 2013.11.05 AEM
0.3 2014.02.28 AEM
Copyright © 2013 congatec AG
• Preliminary release
• Corrected the LVDS data rates/resolutions supported in sections 2.1 "Feature List" and 5.8 "LVDS".
• Added information about the Atheros Quadcomm Ethernet PHY for conga-QMX6 revision B.0 in sections 2.1 "Feature List" and 5.3 "Gigabit
Ethernet".
• Updated section 4 "Heatspreader". Added additional heatspreader variants.
• Updated section 5.2 "UART". Updated section 5.13 "Manufacturing/Jtag Interface".
• Added pin descriptions for the onboard UART connector and the RS-232 adapter cable in section 10.1 "UART/RS-232 Debug Port".
• Added section 10.3 "JTAG Interface".
• Added the new Ethernet PHY (Qualcomm Atheros) for conga-QMX6 revision B.x to relevant sections.
• Changed the eMMC value of industrial variants from 2G to 4G
• Deleted the row "RSVD" from table 23 " Manufacturing Signal Description".
• Edited section 5.2 "UART" and added caution statement.
• Updated the whole document.
