A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model.
CODE PART
A1 Lava Rock Rack
A2 Burner
A3 Hood Lower Handle
A4 Hood
A5 Body
A6 Grease Cup Holder
A7 Grease Cup
A8 Cooking Grill
Body
Assembly
A9 Lava Rock (Shrink Packed)
A10 Hood Upper Handle
A11 Hinge Bracket
A12 Main Electrode & Gas Collector Box
A13 Heat Shield
A14 Warming Rack
A15 Sillcon Bumpers
A16 Body Support
B1 Control Panel
B2 Igniter Button
B3 Main Burner Knob
B4 Trolley Handle
B5 Main Burner Hose
B6 Side Shelf
Upper
Trolley
B7 Side Burner Knob
B8 Side Burner
B9 Side Burner Shelf
B10 Side Burner
B11 Side Burner Electrode
B12 Side Burner Valve/Hose Assembly
C1 Short Leg Front
C2 Short Leg Rear
C3 Gas Cylinder Holder
C4 Wheel
C5 Axle
Lower
Trolley
C6 Leg End Loop
C7 Long Leg Front
C8 Long Leg Rear
C9 Bottom Shelf
C10 Gas Bottle Strap
D1 M6x15 Bolt
D2 M5x10 Bolt
D3 M4x10 Bolt
D4 ST4.0x10 Screw
Hardware
D5 ST4.8x15 Screw
D6 M8 Locknut
D7 M5 Keps Nut
D8 Wheel Spacer
D9 Shelf Spacer
Rack
Pre-Assembled
Quantity and specification varies according to model purchased.
OUTBACK® EXCEL RANGE
QTY EXCEL 100
√
1
√
1
√
1
√*
1
√*
1
√
1
√
1
√
1
√*
1
√*
1
√*
2
√
1
√
1
√
1
√
2
√
2
√
1
√*
1
√*
2
√
1
√*
1
▲
1
1
1
1
1
1
√
1
√
1
√
1
√
2
√
1
√
1
√
1
√
1
√
1
√*
1
▲ 24
√
4
1
√
2
√
2
√
2
√
2
√
2
▲
2
EXCEL 200 EXEL 300
√ √
√ √
√ √
√* √*
√* √*
√ √
√ √
√ √
√* √*
√* √*
√* √*
√ √
√ √
√ √
√ √
√ √
√ √
√* √*
√* √*
√* √*
2 1
√
√
√
√
√
√*
√ √
√ √
√ √
√ √
√ √
√ √
√ √
√ √
√ √
√* √*
28 28
√ √
√
√ √
√ √
√ √
√ √
√ √
8 4
