REVO RT
from 35A to 90A
P5 - Offset input Loop 1 (Address ModBus 2005)
P19 - Offset input Loop 2 (Address ModBus 2019)
P33 - Offset input Loop 3 (Address ModBus 2033)
Value in algebraic sum to the displayed process
-10000 ÷ +10000 [digit] (degrees.tenths for temperature sensors).
Default: 0
P6 - Multiplier Loop 1 (Address ModBus 2006)
P20 - Multiplier Loop 2 (Address ModBus 2020)
P34 - Multiplier Loop 3 (Address ModBus 2034)
Displayed process multiplier value expressed as a percentage of full scale
Example: to correct a display with a scale from 0 ÷ 1000 ° C that displays 0 ÷ 1010 ° C, set the parameter to -1.0%,
→
1000 (-1%) = -10 1010 + 10 = 1000
*
-1000 (-100.0%) ÷ 1000 ( + 100.0%),
Default: 0.0%.
P7 - Filter Loop 1 (Address ModBus 2007)
P21 - Filter Loop 2 (Address ModBus 2021)
P35 - Filter Loop 3 (Address ModBus 2035)
Filter used to increase the stability of the reading
Increasing the value slows down the speed of the control loop
1 ÷ 15.
Default: 10
P8 - Unit of measurement for all Loops (Address ModBus 2008)
0 °C - Celsius Degrees (Default)
1 °F - Fahrenheit Degrees
2 K - Kelvin
P9 - Conversion rate for all Loops (Address ModBus 2009)
Sampling frequency of the input.
Increasing the conversion speed decreases the reading stability.
(example: for fast variables such as pressure, it is advisable to increase the sampling rate).
0 4.17 Hz (Minimum conversion speed)
1 6.25 Hz
2 8.33 Hz
3 10.0 Hz
4 12.5 Hz
5 16.7 Hz (Default) Ideal for noise filtering 50 / 60 Hz
6 19.6 Hz
7 33.2 Hz
8 39.0 Hz
9 50.0 Hz
10 62.0 Hz
11 123 Hz
12 242 Hz
13 470 Hz (maximum conversion speed)
P14 - Decimal point Loop 1 (Address ModBus 2014)
P28 - Decimal point Loop 2 (Address ModBus 2028)
P42 - Decimal point Loop 3 (Address ModBus 2042)
Number of decimal places; read-only value. The value depends on the selected input type
