AT 6 - TEXAN.
Adjustable Servo connector
Servo arm
4) Install servos arm to servos. Notice the
position of the servo arms on the servos. See
picture below.
Elevator.
Rudder.
Elevator.
Switch.
Throttle.
C/A glue attached.
Instruction Manual.
MOUNTING THE TAIL WHEEL BRACKET.
1) Set the tail wheel assembly in place on
the plywood plate. The pivot point of the tail
wheel wire should be even with the rudder
hinge line and the tail wheel bracket should
be centered on the plywood plate.
2) Using a pen, mark the locations of the
two mounting screws. Remove the tail wheel
bracket and drill 1mm pilot holes at the loca-
tions marked.
3) Secure the tail wheel bracket in place
using two 3mm x 15mm wood screws. Be
careful not to overtighten the screws.
