- Page 1 Motion SP primax User Guide Signia Motion SP primax EN__COB.indd 1 10.05.2019 11:18:46...
-
Page 2: Table Of Contents
Battery size and handling tips Replacing batteries Child lock (optional) Daily use Turning on and off Inserting and removing the hearing instruments 19 Adjusting the volume Changing the hearing program Locking the controls (optional) Further adjustments (optional) Signia Motion SP primax EN__COB.indd 2 10.05.2019 11:18:46... - Page 3 Audio induction loops Audio input (FM system) Maintenance and care Hearing instruments Ear pieces and tubes Professional maintenance Further information Safety information Wireless functionality Accessories Symbols used in this document Troubleshooting Country-specific information Service and warranty Signia Motion SP primax EN__COB.indd 3 10.05.2019 11:18:46...
-
Page 4: Welcome
This will help you get adjusted to them. CAUTION It is important to read this user guide and the safety manual thoroughly and completely. Follow the safety information to avoid damage or injury. Signia Motion SP primax EN__COB.indd 4 10.05.2019 11:18:46... -
Page 5: Your Hearing Instruments
If you have problems pressing the controls of your hearing instruments while wearing them, you can ask your Hearing Care Professional about a remote control option. Signia Motion SP primax EN__COB.indd 5 10.05.2019 11:18:46... -
Page 6: Components And Names
(optional) ➌ Push button (control) ➏ Battery compartment (on/off switch) ➍ LED status indicator Your Hearing Care Professional will attach a tube and a custom-made ear piece to each hearing instrument. Signia Motion SP primax EN__COB.indd 6 10.05.2019 11:18:48... -
Page 7: Controls
Your Hearing Care Professional has programmed your desired functions to the controls. Control Left Right Push button Rocker switch You can also use a remote control or a smartphone app to control your instruments. Signia Motion SP primax EN__COB.indd 7 10.05.2019 11:18:50... - Page 8 Push button function Press briefly: Program change Press long: Standby/turn on L = Left, R = Right Push button and rocker switch function Lock/Unlock the controls Read more in section "Locking the controls". L = Left, R = Right Signia Motion SP primax EN__COB.indd 8 10.05.2019 11:18:56...
-
Page 9: Settings
Read more in section "On the phone". TwinPhone transmits the telephone call into both ears when the telephone receiver is held to either ear. Read more in section "On the phone". Signia Motion SP primax EN__COB.indd 9 10.05.2019 11:18:57... - Page 10 A telecoil is built into the instrument, so it can connect with audio induction loops. Read more in section "Audio induction loops". The e2e wireless functionality enables simultaneous control of both hearing instruments. Read more in section "Wireless functionality". Signia Motion SP primax EN__COB.indd 10 10.05.2019 11:18:58...
-
Page 11: Batteries
5 seconds until the battery is empty. ● When the battery is empty, the LED goes out. When the battery compartment is locked, you need a tool to open it. Read more in section "Child lock". Signia Motion SP primax EN__COB.indd 11 10.05.2019 11:18:58... -
Page 12: Battery Size And Handling Tips
Remove the batteries if you intend not to use the hearing instruments for several days. ● Always carry spare batteries. ● Remove empty batteries immediately and follow your local recycling rules for battery disposal. Signia Motion SP primax EN__COB.indd 12 10.05.2019 11:18:58... -
Page 13: Replacing Batteries
Carefully close the battery compartment. If you feel resistance, the battery is not inserted correctly. Do not attempt to close the battery compartment by force. It can be damaged. Signia Motion SP primax EN__COB.indd 13 10.05.2019 11:19:07... -
Page 14: Child Lock (Optional)
Opening a locked battery compartment: Use the tool to push the white locking bar to the opposite side. Hold it in place and at the same time open the battery compartment. Signia Motion SP primax EN__COB.indd 14 10.05.2019 11:19:07... - Page 15 To lock it, the Hearing Care Professional has to remove the highlighted part. The lower image shows a locked battery compartment. To unlock it, the Hearing Care Professional has to install a child lock disabler. Signia Motion SP primax EN__COB.indd 15 10.05.2019 11:19:08...
- Page 16 Unlocking the battery compartment: Push the locking bar with the child lock disabler to the other side. Ensure that the child lock disabler is completely inserted. Rotate the shaft to break it off. Signia Motion SP primax EN__COB.indd 16 10.05.2019 11:19:14...
-
Page 17: Daily Use
After turning on, the previously used volume and hearing program remain set. Via remote control: Follow the instructions in the remote control's user guide. After turning on, the previously used volume and hearing program remain set. Signia Motion SP primax EN__COB.indd 17 10.05.2019 11:19:14... - Page 18 During this time you can insert the hearing instruments into your ears without experiencing unpleasant feedback whistling. The "power-on delay" can be activated by your Hearing Care Professional. Signia Motion SP primax EN__COB.indd 18 10.05.2019 11:19:14...
-
Page 19: Inserting And Removing The Hearing Instruments
● If you have problems inserting the ear piece, use the other hand to gently pull your earlobe downwards. This opens the ear canal and eases insertion of the ear piece. Signia Motion SP primax EN__COB.indd 19 10.05.2019 11:19:16... -
Page 20: Adjusting The Volume
Refer to section "Controls" for the setting of the rocker switch. An optional signal tone can indicate the volume change. Once the maximum or minimum volume has been reached, you may hear an optional signal tone. Signia Motion SP primax EN__COB.indd 20 10.05.2019 11:19:18... -
Page 21: Changing The Hearing Program
Your Hearing Care Professional can configure your hearing instruments so that they switch automatically to the audio shoe program if the audio shoe has been attached. Read more in section "Audio input". Signia Motion SP primax EN__COB.indd 21 10.05.2019 11:19:18... -
Page 22: Locking The Controls (Optional)
Sound balance allows you to adjust the bass and treble to your preferences. Refer to section "Controls" for the setting of your controls. Signia Motion SP primax EN__COB.indd 22 10.05.2019 11:19:18... -
Page 23: Special Listening Situations
Hearing Care Professional. Refer to section "Controls" for the setting of the rocker switch. With a suitable smartphone app you have even more control options. Signia Motion SP primax EN__COB.indd 23 10.05.2019 11:19:19... - Page 24 An optional signal tone can indicate the minimum and maximum level. Toggle one step further. The same signal tone as for changing the hearing program is played, indicating that you have exited the spatial configurator mode. Signia Motion SP primax EN__COB.indd 24 10.05.2019 11:19:19...
-
Page 25: On The Phone
Switch to the telephone program whenever you are on the phone or use the automatic program switch. If a telephone program or the automatic program switch are configured for your hearing instruments, it is listed in section "Settings". Signia Motion SP primax EN__COB.indd 25 10.05.2019 11:19:19... - Page 26 See the AutoPhone magnet user guide for instructions on how to position the magnet. NOTICE Use the approved AutoPhone magnet only. Ask your Hearing Care Professional for this accessory. Signia Motion SP primax EN__COB.indd 26 10.05.2019 11:19:19...
-
Page 27: Audio Induction Loops
For instruments with wireless connectivity: When the telecoil program is active, the remote control may cause a pulsing noise. Use the remote control with a distance greater than 10 cm (4 inches). Signia Motion SP primax EN__COB.indd 27 10.05.2019 11:19:20... -
Page 28: Audio Input (Fm System)
Configure the hearing instruments so that they switch automatically to the audio shoe program if the audio shoe has been attached. ● Use an approved audio shoe only. Ask your Hearing Care Professional for this accessory. Signia Motion SP primax EN__COB.indd 28 10.05.2019 11:19:20... - Page 29 Hold the audio shoe tightly when you remove the FM receiver. A ttaching the audio shoe Open the battery compartment. Pull the cover out. The shape of the cover depends on your type of hearing instrument. Signia Motion SP primax EN__COB.indd 29 10.05.2019 11:19:23...
- Page 30 Slide the audio shoe in. Ensure that it clicks click noticeably in place. Close the battery compartment. Signia Motion SP primax EN__COB.indd 30 10.05.2019 11:19:29...
- Page 31 Slide the cover in the direction of the arrow into position. The shape of the cover depends on your type of hearing instrument. Close the battery compartment. Signia Motion SP primax EN__COB.indd 31 10.05.2019 11:19:33...
-
Page 32: Maintenance And Care
Never apply pressure while cleaning. Ask your Hearing Care Professional for recommended cleaning products, special care sets, or more information on how to keep your hearing instruments in good condition. Signia Motion SP primax EN__COB.indd 32 10.05.2019 11:19:33... -
Page 33: Ear Pieces And Tubes
Custom-made ear pieces and wax filters should be exchanged as needed by your Hearing Care Professional. Ask your Hearing Care Professional for your individual recommendation of maintenance intervals and for support. Signia Motion SP primax EN__COB.indd 33 10.05.2019 11:19:33... -
Page 34: Further Information
Some hearing instrument types support CROS and BiCROS solutions for people with single-sided deafness. Consult your Hearing Care Professional for further information. Signia Motion SP primax EN__COB.indd 34 10.05.2019 11:19:33... -
Page 35: Symbols Used In This Document
● Clean the ear piece. Sound is distorted. ● Decrease the volume. ● Replace the empty battery. ● Clean the ear piece. Hearing instrument emits signal tones. ● Replace the empty battery. Signia Motion SP primax EN__COB.indd 35 10.05.2019 11:19:34... - Page 36 Replace the empty battery. ● Make sure the battery is inserted correctly. ● Power-on delay is active. Wait several seconds and check again. Consult your Hearing Care Professional if you encounter further problems. Signia Motion SP primax EN__COB.indd 36 10.05.2019 11:19:34...
-
Page 37: Country-Specific Information
Country-specific information Signia Motion SP primax EN__COB.indd 37 10.05.2019 11:19:34... - Page 38 Signia Motion SP primax EN__COB.indd 38 10.05.2019 11:19:34...
-
Page 39: Service And Warranty
Service and warranty Serial numbers Left: Right: Service dates Warranty Date of purchase: Warranty period in months: Your Hearing Care Professional Signia Motion SP primax EN__COB.indd 39 10.05.2019 11:19:34... - Page 40 Signia GmbH Henri-Dunant-Strasse 100 91058 Erlangen Germany Phone +49 9131 308 0 Document No. 03119-99T04-7600 EN Order/Item No. 109 447 04 0123 Master Rev04, 04.2019 © 04.2019, Signia GmbH. All rights reserved www.signia-hearing.com Signia Motion SP primax EN__COB.indd 40 10.05.2019 11:19:34...
