Directed Directechs DS4+ Installation Manual page 14

Wire Information
Function Color
Chevrolet Malibu Limited 2016
Immo. Data Green/Violet
12V Red/Blue
Accessory Yellow
Ignition Violet
Drivers Door Trigger Gray
Gray
Parking Lights
Blue
HS CAN High
White
HS CAN Low
Green
SW CAN
Chevrolet Orlando 2012-2013
Immo. Data Green/Violet
12V Red/Violet
Accessory Violet/Yellow
Ignition Violet/Black
Drivers Door Trigger Gray
Parking Lights Green/Gray
HS CAN High Blue
HS CAN Low White
SW CAN Green
Chevrolet Sonic 2012-2016
Immo. Data Green/Violet
12V Red/Violet
Accessory Violet/Yellow
Ignition Violet/Black
Drivers Door Trigger Gray
Parking Lights Green/Gray
HS CAN High Blue
HS CAN Low White
SW CAN Green
Clutch Yellow
Chevrolet Trax 2013-2018
Immo. Data Green/Violet
12V Red/Yellow
Accessory Violet/Yellow
Ignition Violet/Black
Drivers Door Trigger Gray
Parking Lights Green/Gray
HS CAN High Blue
HS CAN Low White
SW CAN Green
14
Pin Polarity Location
2 Data Transponder Key Amplifier on ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
Driver Window Switch (driver window auto down only)
6 (-)
Driver Window Motor (driver window auto up & down)
3 (-)
Headlight switch.
6 Data
OBDII.
14 Data
OBDII.
1 Data
OBDII.
2 Data Transponder Key Amplifier on ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
6 (-) Driver window module in drivers door.
3 (-) Headlight switch.
6 Data OBDII.
14 Data OBDII.
1 Data OBDII.
2 Data Transponder Key Amplifier on ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
6 Driver window module (with power windows)
(-)
22 BCM, above driver kick panel (without power windows)
3 (-) Headlight switch.
6 Data OBDII.
14 Data OBDII.
1 Data OBDII.
B MUX Clutch pedal switch.
2 Data Transponder Key Amplifier on ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
6 (-) Driver window module in drivers door.
3 (-) Headlight switch.
6 Data OBDII.
14 Data OBDII.
1 Data OBDII.
Connector Information
Color
Violet
Black
Black
Black
Black
Black
Black
Black
Black
Black
Violet
Black
Black
Black
Black
Black
Black
Black
Black
Violet
Black
Black
Black
Black
Pink
Black
Black
Black
Black
Black
Violet
Black
Black
Black
Black
Black
Black
Black
Black
© 2017-10-19 Directed. All rights reserved.
Pins Ref.
3 A
6 B
6 B
6 B
8 F
7 F
12 E
16 E
16 E
16 E
3 A
6 B
6 B
6 B
7 F
12 D
16 E
16 E
16 E
3 A
6 B
6 B
6 B
7 F
27 G
12 D
16 E
16 E
16 E
3 H
3 A
6 B
6 B
6 B
7 F
12 D
16 E
16 E
16 E
DS4+ GM10
