Directed Directechs DS4+ Installation Manual page 23

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Chevrolet Colorado 2015-2018
Immo. Data Lt. Green/Violet
12V Red/Blue
Accessory Violet/Yellow
Ignition Violet/Black
Drivers Door Trigger Gray
Parking Lights Lt. Green/Gray
HS CAN High Lt. Blue
HS CAN Low White
SW CAN Lt. Green
Lock Brown/Yellow
Unlock Brown/White
Clutch Yellow
Chevrolet Spark 2016-2017
Immo. Data Lt. Green/Violet
12V Red/Violet
Accessory Violet/Yellow
Ignition Violet/Black
Parking Lights Green/Brown
HS CAN High Blue
HS CAN Low White
SW CAN Green
Drivers Door Trigger Gray
Lock Brown/Yellow
Unlock Brown/White
Clutch Yellow
23
Pin Polarity Location
2 Data Transponder Key Amplifier on ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
6 (-) Driver window module in drivers door.
5 (-) Headlight switch.
6 Data OBDII.
14 Data OBDII.
1 Data OBDII.
19 (-) BCM, above driver kick panel.
15 (-) BCM, above driver kick panel.
B MUX Clutch pedal switch.
2 Data Transponder Key Amplifier on ignition switch.
2 (+) Ignition switch.
3 (+) Ignition switch.
1 (+) Ignition switch.
5 (-) Headlight switch.
6 Data OBDII.
14 Data OBDII.
1 Data OBDII.
22 (-) BCM, above driver kick panel.
15 (-) BCM, above driver kick panel.
14 (-) BCM, above driver kick panel.
B MUX Clutch pedal switch.
Connector Information
Color
Violet
Black
Black
Black
Black
Black
Black
Black
Black
Blue
Blue
Black
Violet
White
White
White
Black
Black
Black
Black
Pink
Pink
Gray
Black
© 2017-10-19 Directed. All rights reserved.
Pins Ref.
3 A
6 B
6 B
6 B
7 F
12 D
16 E
16 E
16 E
27 C
27 C
3 H
3 A
6 B
6 B
6 B
12 D
16 E
16 E
16 E
27 C
27 C
27 G
3 H
DS4+ GM10
